Neutrik // NTP3RC - 3.5 mm Tiny Plug
The brand new NPT3RC is the perfect plug for professional applications requiring 3.5mm stereo plugs, like wireless headsets, portable CD/MP3 players, mic connections on video cameras, etc.
3 pole 3.5 mm audio plug, solder termination, chuck type strain relief, bushing, black housing, gold contacts
The only right-angled metal bodied 3.5 mm jack plug with chuck type strain relief for secure cable retention. It accepts cables from 2.0 to 4.5 mm.







Features & Benefits

All metal housing - robust and reliable
Chuck type cable clamp and rubber gland - excellent cable protection
Slim design - space saving










There are no technical infos for this product.(210_459854644)







Product


Connector Type
Plug


Gender
male


Electrical


Contact resistance
depends on mating connector mΩ


Dielectric strength
1 kVdc


Insulation resistance
> 2 GΩ (initial)


Insulation resistance
≥ 1 GΩ (after damp heat test)


Rated current per contact
≤ 15 A


Mechanical


Cable O.D.
2 - 4.5 mm


Wire size
0,22 mm²


Wire size
24 AWG


Wiring
Solder contacts


Material


Bushing
Brass (CuZn39Pb3) + PU, black Cr


Contact plating
0.2 µm Au


Contacts
Brass (CuZn39Pb3)


Insert
Polyamide (PA 6.6 15 % GR)


Shell
Zinc diecast (ZnAl4Cu1)


Shell plating
Black chromium


Strain relief
Polyacetal (POM)


Environmental


Solderability
Complies with IEC 68-2-20


Temperature range
-20 °C to +65 °C
