Frequency Range: <10 Hz to >100 kHz (-3 dB@ 40 dB Gain)
Mains Power Supply: Input Voltage; frequency: 100-120 V and 220-240 V; 50 Hz/60 Hz
Power Consumption: max. 25 W
Microphone Inputs: Connector: 2 x XLR 3 F
Microphone Inputs: Input Impedance: approx. 3 kΩ
Microphone Inputs: Minimum Gain: +20 dB (PAD off)
Microphone Inputs: Maximum Gain: +60 dB (PAD off)
Microphone Inputs: Attenuation PAD switchable: off/-20 dB
Microphone Inputs: Maximum Input Level (PAD off): +8 dBu
Microphone Inputs: Maximum Input Level (PAD on): +28 dBu
Microphone inputs: EIN @ 60 dB Gain / 50 Ohm¹⁾: -129,4 dBu(A)
Microphone inputs: EIN @ 40 dB Gain / 50 Ohm¹⁾: -129,2 dBu(A)
Microphone inputs: THD Mic In @ 1kHz /40 dB Gain / +12 dBu²⁾: 0,00018%
Power Supply (P48, IEC 61938): 48 V, max. ≥ 10 mA, switchable on/off
Hi-Z Inputs: Active: switchable on/off
Hi-Z Inputs: Connector: 2 x Jack 6.3 mm (1/4”), mono, unbalanced (front)
Hi-Z Inputs: Input Impedance: 3.3 MΩ
Hi-Z Inputs: Maximum Input Level: +21 dBu
Hi-Z Inputs: Minimum Gain: 0 dB (PAD off)
Hi-Z Inputs: Maximum Gain: +40 dB (PAD off)
Bargraphs per Channel: -24 dBu to +24 dBu in 6 dB steps
Bargraphs Peak Hold: indication @ +24 dBu (hold time approx. 3 sec.)
Headphone Output: Mono/Stereo: switchable
Headphone Output: Connector: jack 6.3 mm (1/4”), stereo (front)
Headphone Output: Volume Control: for left & right channel + Master
Headphone Output: Output Impedance: approx. 2 Ω
Headphone Output: Maximum Output Level: +20 dBu into 150 Ω load impedance
Outputs: Connector: 2 x XLR 3 M
Outputs: Output Impedance: approx. 200 Ω
Outputs: Maximum Output Level: +26 dBu into 1 kΩ load impedance
High Pass Filter: 60 Hz, 12 dB/oct, switchable on /off
Product Dimensions (height x width x depth): 89mm x 483 mm x 242 mm
Weight: 6.2 kg
Operating Conditions: 0°C to +50°C; < 75% RH@ +40°C; non-condensing
Transport/Storage Conditions: -25°C to +70°C; < 95% RH; non-condensing
Working Altitude: < 2000 m
Ground Lift: switchable on/off
