Transmitter:

Analog input level: maximum 2Vrms
Minimum power: 5V @0.5A

Receiver:

Analog output level: maximum 1Vrms
Minimum power requirement: 4.75V @0.3A

Key Specifications:

Dimensions: W 3.15" (80mm) x D 2.36" (60mm) x H 1.02 (26mm)
Weight: 1.25 lbs
Deters against against both in and out of band sources of interference, including: microwaves, wireless cameras, cordless phones, Bluetooth devices and more
Operates seamlessly alongside 802.11b/g/n Wi-Fi
Automatic receiver antenna diversity minimizes fading and multi-path effects
Seamless RF band/channel switching
RF Band – Tri-Band (auto switching) (2.4/5.2/5.8 GHz) – finds the best solution and connects
Three RF frequency ranges for each frequency band:
Band 1: 2400-2483.5MHz
Band 2: 5150-5250MHz
Band 3: 5725-5875MHz
22 Mbps wireless air data rate
Sample Rate: 48kHz
THD+N: -70dB (10Hz – 20kHz)
S/N: +105dB (10Hz - 20kHz)
Cross-talk: >75dB @1KHz
Frequency Response: 6Hz – 20 kHz +/- 0.5 dB
Audio Latency: < 19ms
Transmission Range 130’ (line of sight)

Included in the Box:

Wireless Transmitter
Wireless Receiver
Two AC Power Adapters
Two 24" USB cables for AC power adapter
Two 24" Mono RCA to Mono RCA cables
Two Velcro
Quickstart Guide
