ELECTROCOMPANIET ECP 2 MKII PHONO STAGE Gramofonsko Pretpojačalo
Garantujemo najnižu cenu!
CENA: 2299€
With the renewed international enthusiasm for the vinyl format, a world-class phono preamplifier or RIAA stage is more important in a reference setup than ever before.
The ECP2-MKII has become a new favorite of reviewers and enthusiasts alike. A benchmark product in its price bracket, much like other Electrocompaniet products.
It incorporates state-of-the-art instrumentation and operational amplifiers and highest quality discrete components in the signal path. Of course it is all DC coupled.
The ECP2-MKII introduces new chassis and front plate design, in line with our other products in the Classic Line.
It will make your vinyl records sing like no other phono preamplifier we know of, and it seems the industry agrees with us.
The ECP2-MKII can accommodate any imaginable pickup, MM or MC thanks to its extremely configurable input stage, adjustable gain and the ECP 2 MKII is strictly matched to the RIAA curve.
ECP 2 MKII incorporates state-of-the-art instrumentation and operational amplifiers and highest quality discrete components in the signal path. Of course it is all DC coupled.
EXPERTS SAYS
"...It wears all kinds of music and will be able to lift the sound from the vinyl collection significantly, compared to a built-in phono stage. At the same time, it is also so flexible that you can keep it for many years, no matter what electrical properties the pickup may have...."
Lyd og Bilde
|
Phono section |
|
|
|
Gain @ 1 kHz RCA |
Adjustable 39,8 – 71,4 dB |
|
|
Gain @ 1 kHz XLR |
Adjustable 45,8 – 76,4 dB |
|
|
Resistance loading (RL) |
Adjustable 10 Ω – 47 kΩ |
|
|
Capacitive loading (CL) |
Adjustable 0 – 350 pF |
|
|
Maximum output level: |
17.5 V rms (+ 25 dB V) |
|
|
Overload margin |
> 31 dB @ 1 kHz |
|
|
Output impedance |
100 Ω single-ended, 200 Ω balanced |
|
|
Frequency response |
20 – 20 kHz +/- 0.2 dB |
|
|
RIAA Correction Accuracy |
|
|
|
Subsonic filter |
-3dB @ 11 Hz, 24 dB/octave |
|
|
Channel separation |
> 85 dB, 20 – 20 kHz |
|
|
THD + Noise |
< 0.003 % @ 1 kHz |
|
|
S/N-R |
96 dB, 1 kHz, A-weighted, ref. 10 dB V output |
|
|
S/N-R |
91 dB, 1 kHz, A-weighted, ref. 5 mV input |
|
|
S/N-R |
67.4 dB, 1 kHz, A-weighted, ref. 500 μV input |
|
|
|
|
|
|
|
|
|
|
Dimensions |
|
|
|
Width |
470 mm / 18.5 inches |
|
|
Depth |
373 mm / 14.6 inches |
|
|
Height |
78 mm / 3 inches |
|
|
Weight |
9 kg. / 19.8 lbs. |
