All of MOGAMI 110W AES/EBU digital audio cables are designed with flexibility and handy configuration. Many variations are available from regular application type up to long distance application types, from single core up to 12-core types, internal wiring type, and interconnect application types. Strict tolerance control of impedance within ±5% up to ±10% at the maximum.
| Part No. | W3159 | W3228 | W3080 | W3135 | W3173 | W3160 ‾ W3163 |
| Suggested Maximum applicable length |
150m 492Ft |
300m 1000Ft |
150m 492Ft |
|||
Part No. W3159 is for internal wiring material, Part No.3160 ‾ 3163 are multicore cables and other cables are for regular interconnect application. Part No. W3228 is compact size, flexible and durable cofiguration to meet tiny telephone plug cable clamp, therefore it is recommended for use with rough applications. And, Part No. W3173 is specially designed for long distance application assured over 300m.
However, above suggested maximum applicable length is based on use with any device that meets AES standard requirement without equalizer. In the case of use with an equalizer, the maximum applicable length can be expanded up to 1.5 times longer than assured length above. We have also prepared CAD program to see the changes of eye-diagram and transmitted wave form at the receiving end for various working conditions. Since AES/EBU digital audio cable is low capacitance characteristics, it can result in high quality analog audio transmission in general especially for high frequency range.
Bantam Patch Cord
| Part No. | PJD-12 | PJD-18 | PJD-24 | PJD-36 | PJD-48 | PJD-60 | PJD-72 |
| Length | 12" 30cm |
18" 45cm |
24" 60cm |
36" 90cm |
48" 120cm |
60" 150cm |
72" 180cm |
Cable: Part No. W3228; Standard Color: Black only
SPECIFICATIONS
| Configuration |  |
 |
 |
|
 |
|
| Part No. | W3159 | W3228 | W3080 | W3135 | W3173 | |
| No. of Conductor | 2 | 2 | 2 | 2 | 2 | |
| Conductor | Details | 7/0.20A (7×#32AWG) | 36/0.08OFC (36×#40AWG) | 7/0.18A (7×#33AWG) | 7/0.18A (7×#33AWG) | 19/0.25A (19×#31AWG) |
| Size | 0.22mm² (#24AWG) | 0.18mm² (#25AWG) | 0.178mm² (#25AWG) | 0.178mm² (#25AWG) | 0.932mm² (#18AWG) |
|
| Insulation | Ov. Dia. (mm) |
1.35Ø (0.053") | 1.35Ø (0.053") | 1.36Ø (0.054") | 1.36Ø (0.054") | 2.8Ø (0.110") |
| Material | CPP | XLPE | XLPE | XLPE | CPP | |
| Colors | Red/Light green | Red/Clear | Red/Clear | Red/Clear | Red/White | |
| Mono- filament Filler |
Ov. Dia. (mm) |
- | - | - | 1.87Ø (0.0736") | |
| Material | Cotton | LDPE (Clear) | ||||
| Drain Wire | Details | 7/0.20A (7×#32AWG) | - | 7/0.18A (7×#33AWG) | 7/0.18A (7×#33AWG) | 20/0.18TA (20×#33AWG) |
| Size | 0.22mm² (#24AWG) | - | 0.178mm² (#25AWG) | 0.178mm² (#25AWG) | 0.509mm² (#21AWG) |
|
| Served Shield | Approx. 79/0.10A (Approx. 79/#39AWG) |
Approx. 98/0.10A (Approx. 98/#39AWG) |
Approx. 60/0.12A (Approx. 60/#37AWG) |
Approx. 60/0.12A (Approx. 60/#37AWG) |
Approx. 100/0.18A (Approx. 100/#33AWG) |
|
| Ov. Jacket | Ov. Dia. (mm) |
3.2Ø (0.126"Ø) | 4.8Ø (0.189"Ø) | 5.0±0.3Ø (0.197± 0.0118"Ø) |
5.0±0.3Ø (0.197± 0.0118"Ø) |
7.8±0.5Ø (0.307± 0.0197"Ø) |
| Material | PVC | PVC | Flexible PVC | Flexible PVC | PVC | |
| Color | Black/Gray | Black | Black / Blue | Black | Black | |
| Roll Sizes | 50m (164 Ft) / 100m (328Ft) / 200m (656Ft) | 77m (250 Ft) / 305m (1,000Ft) | 300m (983Ft) | |||
| Weight | 2kg/100m Roll | 3kg/100m Roll | 3.3kg/100m Roll | 2.6kg/250m Roll | 27kg/300m | |
ELECTRICAL & MECHANICAL CHARACTERISTICS
| Part No. | W3159 | W3228 | W3080 | |
| DC Resistance at 20°C | Inner Cond. | 0.081Ω/m(0.0247Ω/Ft) | 0.1Ω/m(0.031Ω/Ft) | 0.11Ω/m(0.034Ω/Ft) |
| Shield Cond. | 0.024Ω/m(0.0073Ω/Ft) | 0.025Ω/m(0.0076Ω/Ft) | 0.028Ω/m(0.0085Ω/Ft) | |
| Capacitance at 1kHz, 20°C (effective capacitance value between inner twin) |
46pF/m (14pF/Ft) |
53pF/m (16pF/Ft) |
46pF/m (14pF/Ft) |
|
| Inductance | 0.8µH/m (0.24µH/Ft) | 0.8µH/m (0.24µH/Ft) | 1.0µH/m (0.31µH/Ft) | |
| Characteristic Imperdance | 110Ω±10% | 110Ω±5% | 110Ω±5% | |
| Attenuation (6MHz) | 0.065dB/m (0.020db/Ft) |
0.069dB/m (0.021db/Ft) |
0.069dB/m (0.021db/Ft) |
|
| Phase Constant (6MHz) | 0.17rad/m | 0.20rad/m | 0.20rad/m | |
| Electrostatic Noise* | 50mV Max. | |||
| Electromagnetic Noise at 10kHz* | 2.0mV Max. | |||
| Microphonics** | 60mV | 40mV Max. | 40mV Max. | |
| Voltage Breakdown | Must withstand at DC 500V/15sec, 20°C | |||
| Insulation Resistance | 10000 MΩ × m Min. at DC 250V, 20°C | |||
| Flex Life* | 2,900 cycles | 33,000 cycles | 10,000 cycles | |
| Tensile Strength | 303N | 441N | 343N | |
| Emigration | Non-Emigrant to ABS resin | |||
| Applicable Temperature | -20°C‾ +60°C(-4°F‾ +140°F) | |||
| Standard | AES3-100X (ANSI S. 4. 40-199-X) EBU Rech, 3250-E CEI / IEC 958 / CCIR Rec. 647 |
AES3-100X (ANSI S. 4. 40-199-X) EBU Rech, 3250-E CEI / IEC 958 / CCIR Rec. 647 UL AWM 2623, 30V, 80°C, VW-1 |
AES3-100X (ANSI S. 4. 40-199-X) EBU Rech, 3250-E CEI / IEC 958 / CCIR Rec. 647 |
|
ELECTRICAL & MECHANICAL CHARACTERISTICS
| Part No. | W3135 | W3173 | |
| DC Resistance at 20°C | Inner Cond. | 0.11Ω/m(0.034Ω/Ft) | 0.02Ω/m(0.006Ω/Ft) |
| Shield Cond. | 0.028Ω/m(0.0085Ω/Ft) | 0.007Ω/m(0.0021Ω/Ft) | |
| Capacitance at 1kHz, 20°C (effective capacitance value between inner twin) |
46pF/m (14pF/Ft) |
50pF/m (15.3pF/Ft) |
|
| Inductance | 1.0µH/m (0.31µH/Ft) | 0.7µH/m (0.21µH/Ft) | |
| Characteristic Imperdance | 110Ω±5% | 110Ω±10% | |
| Attenuation (6MHz) | 0.069dB/m (0.021db/Ft) |
0.0347dB/m (0.0106db/Ft) |
|
| Phase Constant (6MHz) | 0.20rad/m | 0.17rad/m | |
| Electrostatic Noise* | 50mV Max. | ||
| Electromagnetic Noise at 10kHz* | 2.0mV Max. | ||
| Microphonics** | 40mV Max. | ||
| Voltage Breakdown | Must withstand at DC 500V/15sec, 20°C | ||
| Insulation Resistance | 10000 MΩ × m Min. at DC 250V, 20°C | ||
| Flex Life* | 10,000 cycles | 16,000 cycles | |
| Tensile Strength | 362N | Over 980N | |
| Emigration | Non-Emigrant to ABS resin | ||
| Applicable Temperature | -20°C‾ +60°C(-4°F‾ +140°F) | ||
| Standard | AES3-100X (ANSI S. 4. 40-199-X) EBU Rech, 3250-E CEI / IEC 958 / CCIR Rec. 647 UL444, CM, 300V, 60°C, #25AWG |
AES3-100X (ANSI S. 4. 40-199-X) EBU Rech, 3250-E CEI / IEC 958 / CCIR Rec. 647 UL AWM 2552, 30V, 60#176;C, VW-1, #18AWG |
|
* Using standard testing method of Mogami Wire & Cable Corp.
W3080
W3135
W3173
| Option: | FERRITE CORE is available for Part No. W3080 and No. W3135 to eliminate EMI noise. FITTING TUBING for ITT CANNON XLR connector is available for Part No. W3080 and No. W3135 cable. |
Like the world standard MOGAMI multicore microphone "Snake" cable, very flexible and compact design makes these multicore 110Ω AES/EBU DIGITAL AUDIO cables easy for wiring, installation and handling.
- Because of employed cellular PP (polypropylene) insulation material, regardless of its compact overall diameter, larger conductor size is used, which naturally results in lower attenuation.
- Besides, there are the following outstanding features similar to the standard analog multipair cables:
- Easy cable core identification system, such as numbered cable core
- Easy wiring assisted by the same conductor size drain wire
- Flexible and good low temperature characteristic
| freq kHz | abs(z)ohm | arg(z)rad | atten npr/m | phase rad/m |
| 10 | 253.053778 | -0.666284 | 0.000485 | 0.000617 |
| 20 | 186.122587 | -0.559186 | 0.000611 | 0.000978 |
| 50 | 140.097832 | -0.348423 | 0.00074 | 0.002038 |
| 100 | 127.900865 | -0.206205 | 0.000811 | 0.003876 |
| 200 | 123.592395 | -0.124331 | 0.000951 | 0.007596 |
| 500 | 120.029543 | -0.080112 | 0.001498 | 0.018508 |
| 1000 | 117.020927 | -0.0671 | 0.00236 | 0.036164 |
| 2000 | 114.290764 | -0.0558 | 0.003866 | 0.070617 |
| 5000 | 111.573232 | -0.04365 | 0.007263 | 0.173456 |
| 10000 | 110.521001 | -0.0358 | 0.012238 | 0.351575 |
|
Part No.
|
Nos. of Cores.
|
O.D. (Approx. mm)
|
Jacket Thickness (Approx. mm)
|
Weight (Kg/100m)(Kg/328Ft)
|
Maximum Length available
|
|
W3160
|
2-CR
|
9.0 (0.354")
|
1.0 (0.039")
|
8
|
305m (1,000Ft)
|
|
W3161
|
4-CR
|
10.5 (0.413")
|
1.2 (0.047")
|
14
|
|
|
W3162
|
8-CR
|
13.8 (0.543")
|
1.4 (0.055")
|
23
|
|
|
W3163
|
12-CR
|
17.0 (0.669")
|
1.6 (0.063")
|
30
|
CABLE CORE SPECS
| Configuration |  |
| Conductor | 7/0.20A (0.22mm²) #24AWG (7×#32AWG) |
| Insulation | 1.35ØCPP (Cellular polypropylene) (0.053") |
| Drain Wire | 7/0.20A (Exactly same as conductor) |
| Shield | Approx. 79/0.10A Served (Spiral) Shield |
| Jacket (covering) | 3.2Ø Flexible PVC (0.126"Ø) |
| Identification | Similar to analog snake cable |
ELECTRICAL & MECHANICAL CHARACTERISTICS
| DC Resistance at 20°C | Inner Pair Cond. | 0.081Ω/m(0.0247Ω/Ft) |
| Shield | 0.024Ω/m(0.0073Ω/Ft) | |
| Capacitance at 1kHz, 20°C (effective capacitance value between inner twin) |
46pF/m(14pF/Ft) | |
| Inductance | 0.8µH/m (0.24µH/Ft) | |
| Characteristic Imperdance | 110Ω±10% | |
| Attenuation (6MHz) | 0.065dB/m (0.020db/Ft) | |
| Phase Constant (6MHz) | 0.17rad/m | |
| Electrostatic Noise* | 5.0mV Max. | |
| Electromagnetic Noise at 10kHz* | 2.0mV Max. | |
| Microphonics* | 60mV | |
| Voltage Breakdown | Must withstand at DC 500V/15sec | |
| Insulation Resistance at DC 125V, 20°C | 10000 MΩ × m Min. | |
| Tensile Strength of one Core | 303N | |
| Emigration | Non-Emigrant to ABS resin | |
| Applicable Temperature | -20°C‾ +70°C(-4°F‾ +158°F) | |
| Standard | AES3-100X(ANSI S.4.40-199X) EBU Rech. 3250-E CEI/IEC 958/CCIR Rec. 647 UL13 CL2X 60°C / UL20002 AWM 30V 60°C VW-1 |
|
-
