Arcam AVA15
Start Your Journey into True High-Fidelity Immersive Surround Sound.
The AVA15 brings breathtaking clarity and depth to every note and every scene, putting you at the heart of the performance. Expertly engineered in Cambridge, UK, and built on over 30 years of surround sound expertise, the AVA15 combines our passion for music with cutting-edge technology. Its powerful Class D amplification and advanced immersive audio processing deliver a sound that’s as thrilling as it is precise. With nine channels of amplification, the AVA15 drives setups like 7.1.2 or 5.1.4 with ease—and gives you room to expand with extra subwoofers, height, or surround speakers. Dolby Atmos and DTS:X bring cinema-grade immersion to your home, while Dirac Live room correction ensures every detail sounds perfect in your space.
Decoding / Encoding
Maximum Channel Count: 12
Reassignable Channels: Front, Surround Back, Height Channels
Supported Decoding and Encoding: Dolby Atmos, Dolby TrueHD, Dolby Atmos Height Virtualisation, Dolby Surround, DTS:X, DTS HD Master, DTS Neural:X, DTS Virtual:X, MPEG H
HDMI
Inputs/Outputs: 7/2
HDMI/HDCP Versions: 2.1a/2.3
Resolution support (resolution/framerate): Up to 8K/60Hz or 4K/120Hz
Supported Dynamic Range Profiles: HDR, HDR10, HDR10+, HDR10+ Gaming, Dolby Vision, HLG
Supported HDMI features: Variable Refresh Rate (VRR), Auto Low Latency Mode (ALLM), CEC, eARC/ARC (Output 1) On Screen Display
Streaming
Works with (apps): ARCAM Radia Control, Spotify Connect, Tidal Connect, Qobuz Connect, Roon (Ready)
Works with (services): Apple Airplay, Google Cast ARCAM Radia supported services, Internet Radio, Podcasts, UPnP
Supported Hi-res media: FLAC, WAV (LPCM), MQA, AAC, ALAC, AIFF, MP3, OGG, WMA
Gapless Playback Supported
Supported Hi-res Bit depth: 16, 24
Supported samples rates (kHz): Up to 192 kHz
Frequency response: 20Hz—20kHz ± 0.05dB
Digital Inputs
Number of inputs (Coaxial/Toslink): 2/2
Supported Sample Rates (kHz):
Coaxial (RCA): 192, 176.4, 96, 88.2, 48, 44.1
Optical (Toslink): 96, 88.2, 48, 44.1
Bit depths (bit) (Coaxial/Toslink): 24, 16
Frequency response: 20Hz—20kHz ± 0.2dB
Signal/noise ratio (A-wtd, ref. 50W, 0dBFS): 100dB
Analogue Inputs
Number of inputs: 3 (RCA pairs)
Signal/noise ratio (A-wtd, ref. 50W, 1V input): 100dB
Frequency response: 20Hz—20kHz ± 0.2dB
Preamplifier Outputs
Number of Outputs RCA/XLR: 12/0
Single-ended (RCA) peak output level per channel: 2V RMS
THD+N (20 Hz to 20 kHz): –100dB
Amplification
Amplifier Channels: 9, Class D
Continuous power output (0.5% THD)
8O, 20Hz - 20kHz, 2 channels driven: 85W
4O, 1kHz, 2 channels driven: 150W
8O, 20Hz - 20kHz, 7 channels driven: 85W
4O, 1kHz, 7 channels driven: 65W
Harmonic distortion @80% power, 8O at 1kHz: 0.003%
General
Mains voltage (V/Hz): 100–120V or 220–240V, 50–60Hz
Max Power consumption: 900W
Max Thermal dissipation: 3070 BTU/hour
Idle Power consumption: 59W
Idle Thermal dissipation: 200 BTU/hour
Standby Power consumption (Default/Low Power): 2W/0.3W
Dimensions W x D (including speaker terminals) x H (including feet): W432 x D407.4 x H170mm
Weight (net): 10kg
Weight (packed): 15.7kg
Supplied accessories:
Region Specific Power Cord(s)
Rear panel cowl
Remote control with 2 x AAA batteries
Measurement Microphone
5m USB Cable
Quick Start Guide
Important Safety Instructions
Wireless Specifications
Bluetooth Version: 5.4
Bluetooth Profiles: A2DP Sink/Source, AVRCP, Snapdragon Sound, AAC, LE Audio, Auracast, GATT, VCP, MCP, BAP, CAP
Bluetooth Transmitter Frequency Range and Power: 2,402 MHz to 2,480 MHz <Max 10.73dBm
Wi-Fi Network: IEEE 802.11 a/b/g/n/ac (2.4GHz/5GHz)
2.4G Wi-Fi Transmitter Frequency Range and Power: 2.400 GHz to 2.4835 GHz < Max 17.4dBm
5G Wi-Fi Transmitter Frequency Range and Power: 5.15-5.35GHz, 5.47-5.725GHz, 5.725-5.875GHz, < Max 19.26dBm
