Arcam AVA35
Â
For those who refuse to compromise, the AVA35 represents the summit of home cinema and musical performance. This is not just an amplifier—it’s ARCAM’s most advanced integrated AV solution, designed for true connoisseurs of sound. Expertly engineered in Cambridge, UK, the AVA35 harnesses our signature Class G amplification, a technology unique to ARCAM and revered for its ability to deliver superior power, lower crossover distortion, and unmatched musicality. Combined with the same high-performance DAC architecture found in our flagship stereo systems, the AVA35 ensures every note and every cinematic moment is rendered with breathtaking clarity and emotional impact. For the ultimate in flexibility, the AVA35 introduces matrix channel assignment, allowing you to reallocate channels freely for the most personalised and immersive configurations. Whether it’s music, movies, gaming, or sport, this amplifier adapts to your vision of perfection.
Decoding / Encoding
Maximum Channel Count: 16
Reassignable Channels: All channels (Subwoofers into CH4 & 11-16 only)
Supported Decoding and Encoding: Dolby Atmos, Dolby TrueHD, Dolby Atmos Height Virtualisation, Dolby Surround
DTS:X, DTS HD Master, DTS Neural:X, DTS Virtual:X, MPEG H, IMAX Enhanced, AURO-3D, AURO-2D
HDMI
Inputs/Outputs: 7/3 (Zone 1 outputs = 2, Zone 2 outputs = 1)
HDMI/HDCP Versions: 2.1a/2.3
Resolution support (resolution/framerate): Up to 8K/60Hz or 4K/120Hz
Supported Dynamic Range Profiles: HDR, HDR10, HDR10+, HDR10+ Gaming, Dolby Vision, HLG
Supported HDMI features: Variable Refresh Rate (VRR), Auto Low Latency Mode (ALLM), CEC, eARC/ARC (Zone 1, Output 1) On Screen Display
Streaming
Works with (apps): ARCAM Radia Control, Spotify Connect, Tidal Connect, Qobuz Connect, Roon (Ready)
Works with (services): Apple Airplay, Google Cast ARCAM Radia supported services, Internet Radio, Podcasts, UPnP
Supported Hi-res media: FLAC, WAV (LPCM), MQA, AAC, ALAC, AIFF, MP3, OGG, WMA
Gapless Playback Supported
Supported Hi-res Bit depth: 16, 24
Supported samples rates (kHz): Up to 192 kHz
Frequency response: 20Hz—20kHz ± 0.05dB
Digital Inputs
Number of inputs (Coaxial/Toslink): 2/2
Supported Sample Rates (kHz):
Coaxial (RCA): 192, 176.4, 96, 88.2, 48, 44.1
Optical (Toslink): 96, 88.2, 48, 44.1
Bit depths (bit) (Coaxial/Toslink): 24, 16
Frequency response: 20Hz—20kHz ± 0.2dB
Signal/noise ratio (A-wtd, ref. 50W, 0dBFS): 100dB
Analogue Inputs
Number of inputs: 3 (RCA pairs)
Signal/noise ratio (A-wtd, ref. 50W, 1V input): 100dB
Frequency response: 20Hz—20kHz ± 0.2dB
Preamplifier Outputs
Number of Outputs RCA/XLR: 16/0
Single-ended (RCA) peak output level per channel: 2V RMS
THD+N (20 Hz to 20 kHz): –100dB
Amplification
Amplifier Channels: 9, Class G
Continuous power output (0.5% THD)
8O, 20Hz - 20kHz, 2 channels driven: 145W
4O, 1kHz, 2 channels driven: 200W
8O, 20Hz - 20kHz, 7 channels driven: 110W
4O, 1kHz, 7 channels driven: 130W
Harmonic distortion @80% power, 8O at 1kHz: 0.004%
General
Mains voltage (V/Hz): 100–120V or 220–240V, 50–60Hz
Max Power consumption: 900W
Max Thermal dissipation: 3070 BTU/hour
Idle Power consumption: 93W
Idle Thermal dissipation: 320 BTU/hour
Standby Power consumption (Default/Low Power): 2W/0.4W
Dimensions W x D (including speaker terminals) x H (including feet): W432 x D459.1 x H170mm
Weight (net): 22.7kg
Weight (packed): 29.4kg
Supplied accessories:
• Region Specific Power Cord(s)
• Rear panel cowl
• Remote control with 2 x AAA batteries
• Measurement Microphone
• 5m USB Cable
• Quick Start Guide
• Important Safety Instructions
Wireless Specifications
Bluetooth Version: 5.4
Bluetooth Profiles: A2DP Sink/Source, AVRCP, Snapdragon Sound, AAC, LE Audio, Auracast, GATT, VCP, MCP, BAP, CAP
Bluetooth Transmitter Frequency Range and Power: 2,402 MHz to 2,480 MHz <Max 10.73dBm
Wi-Fi Network: IEEE 802.11 a/b/g/n/ac (2.4GHz/5GHz)
2.4G Wi-Fi Transmitter Frequency Range and Power: 2.400 GHz to 2.4835 GHz < Max 17.4dBm
5G Wi-Fi Transmitter Frequency Range and Power: 5.15-5.35GHz, 5.47-5.725GHz, 5.725-5.875GHz, < Max 19.26dBm
