ONKYO Muse Y-50
Network Streamer & Integrated High-Power Amplifier
The inspiring Onkyo Muse Y-50 fuses 80 years of Japanese audio expertise into an elegant, 250W hi-fi hub with premium design, smart features, and versatile connectivity.
Features and connectivity
Custom App: Onkyo Control
Room Calibration: Onkyo Room EQ
Analog Audio Input: RCA(Unbalanced) x 3pair
Digital Audio Input:
• HDMI IN x1 (HDCP2.3, 4K/120p, 8K/60p, VRR, QFT, ALLM, QMS, SBTM, DSC, HDR10+, Dolby Vision)
• HDMI ARC
• COAX x 1
• Optical x 1
• USB-A (Storage playback) x 1
HDMI Output: 1
Phono Input: 1 pair (MM/MC)
Audio Pre Output: RCA(Unbalanced) x 1pair
Subwoofer Output: 1ch
Headphone Output: 1/4”(6.3mm) Jack x 1
Network connectivity:
• Wi-Fi
• Ethernet Terminal(10BASE-T/100BASE-TX)
Bluetooth: SBC, AAC
Network service: Spotify connect, TIDAL Connect, Qobuz connect, AirPlay, Google Cast, Music Server
Audio performance
Output power (U.S.A.): 125w (FTC, 8Ω, 20Hz - 20kHz, THD 0.08%, 2ch driven)/ 250w(4Ω, 1kHz, THD 0.7%, 2ch driven)
Output power (EMEA/APAC): 250w(4Ω, 1kHz, THD 0.7%, 2ch driven) / 125w(8Ω, 20Hz-20kHz, THD 0.08%, 2ch driven)
Amplifier channel: 2ch
Pre Amplifier channel: 2.1ch
Amplifier Type: Class D
Frequency Response: 20Hz~30kHz(+1/-3dB)
Tone control (Bass/ Treble): 100Hz ±10dB / 10kHz ±10dB
Speaker impedance: 4-16Ω
General
Product Dimensions (W x H x D):
• 350 x 99 x 337 (mm)
• 13.8 x 3.9 x 13.3 (inches)
Product Weight: 4.9 kg (10.8lbs)
Package Dimensions(W x H x D):
• 465 x 225 x 405 (mm)
• 18.3 x 8.9 x 15.9 (inches)
Package Weight: US: 7.2 kg (15.9lbs) EMEA: 7.6kg (16.8lbs)
Standby Power Consumption:
• Less than 0.4w(Standby)
• Less than 1.8w(Network Standby)
Power Consumption: 120W
AC Voltage: AC 100-240V 50Hz/60Hz
