SPL Performer s1200 - Pojačalo snage
The powerful stereo amplifier
This impressive stereo power amplifier leads even the most demanding speakers to soundscapes beyond your expectations. With a power amplification of 2 x 520 W (4 Ω) [2 x 550 W (2 Ω); 2 x 300 W (8 Ω)], this completely analog amplifier easily controls any loudspeaker.
Thanks to the VOLTAiR technology the performance of the s1200 is detail-rich, vivid, honest and plain simply beautiful.
Analog Inputs: XLR (balanced), RCA (unbalanced)
Input impedance: 20 kΩ
Input trimming: 0 dB to -5.5 dB in 0.5 dB steps
Input sensitivity: 10,5 dBu
Loudspeaker Outputs: Binding posts with 4 mm ø cable hole (screwable) and banana plug
Output power (RMS, 2 Ω): 2 x 550 W
Harmonic distortion (1 kHz, 2 Ω): < 0,09 %
Output power (RMS, 4 Ω): 2 x 520 W
Harmonic distortion (1 kHz, 4 Ω): < 0,09 %
Output power (RMS, 8 Ω): 2 x 300 W
Harmonic distortion (1 kHz, 8 Ω): < 0,04 %
Output voltage (Peak-to-Peak): 160 V
Output voltage (RMS): 54,6 V
Output impedance (20 Hz – 20 kHz): < 0,031 Ω
Frequency range (-3dB): 10 Hz – 80 kHz
Amplification gain: 26 dB
Damping factor (1 kHz, 8 Ω): > 290
Noise (A-weighted): -123 dB
Internal Linear Power Supply with Shielded Toroidal Transformer
Toroidal transformer: 1440 VA
Operating voltage (Input stage): +/- 60 V
Operating voltage (Power stage): +/- 80 V
Operating voltage for relays, LEDs, AMP CTL: + 12 V
Mains Power Supply
Mains voltage (selectable, see fuse chamber): 230 V AC / 50 Hz; 115 V AC / 60 Hz
Fuse 230 V: T 6.3 A
Fuse 115 V: T 10 A
Power consumption: max. 1440 VA
Idle power consumption: 50 W
Stand-by power consumption: < 0.3 W
Dimensions & Weight
W x H x D (width x height incl. feet x depth): 276 x 205 x 345 mm
Unit weight: 25.1 kg
Shipping weight: 29.1 kg
