Monophonic synthesizer
100% Analog audio signal path
Steiner-Parker 2-pole multimode filter (Low Pass, Band Pass, High Pass)
Analog Voltage Controlled Oscillator
Oscillator Mixer (Overtone, Sawtooth, Square, Triangle, audio in [on rear panel])
Overtone sub oscillator/5th generator
Signal enhancers:
• Pulse Width Modulation
• Ultrasaw generates fat sawtooth waveforms
• Metalizer brings in extreme harmonics
Brute Factor™ delivers saturation and rich harmonics
LFO with 3 waveforms (sine, sawtooth, square)
LFO can freerun or sync to arpeggiator
ADSR envelope generator
Keyboard tracking of the VCF cutoff
25-note mini-key keyboard
Mod wheel (assignable to cutoff or LFO amount)
Pitch wheel (bend range selectable via software)
Octave selector from -3 to +2 octaves
External analog audio input
CV In jacks: Pitch, Filter, sub-harmonics, pulse width, Metalizer, saw animator
CV Out jacks: pitch, envelope, LFO
MIDI In with 5 pin DIN connector
USB MIDI In/Out
1/4” audio output and 1/8” headphone output
Full-functioned step sequencer:
• 8 memories
• 7up to 64 steps per memory
• tap tempo
• rate control
• step divisions (via software)
• trigger modes (via software)
MIDI sync
Steel bottom panel
12V DC 1A power supply
Box content
• MicroBrute synthesizer
• User manual
• Preset sheets
• Power supply
• 2 mini-jack patch cords
Size & weight
• Size (mm): 60 x 325 x 221 mm
• Size (in): 2.36 x 12.80 x 8.70 in
• Weight (kg): 1.75 kg
• Weight (lb): 3.86 lb
