Matriarch Features
VOICE MODE: Mono, duo, and 4-note paraphonic playability
ANALOG DELAY: Stereo analog delay w/ up to 700ms of MIDI sync-able stereo or ping/pong style repeats
SEQUENCER: 256 step sequencer w/ up to 4 notes per step and 12 stored patterns. Can be decoupled from Matriarch to independently sequence external gear.
ARPEGGIATOR: Arpeggiator with selectable modes (Order, Forward/Backward, Random).
SEMI-MODULAR DESIGN: Semi-modular analog synthesizer - no patching required.
MODULAR CAPABILITIES: 90 modular patch points for endless exploration
KEYBOARD: Diode Wavefolder
ANALOG OSCILLATORS: 4 analog oscillators w/ selectable waveshape and hard sync per-oscillator.
LFO: Full-range analog LFO with 6 selectable waveshapes.
LADDER FILTERS: Dual analog filters with parallel (HP/LP), stereo (LP/LP), and series (HP/LP) modes available.
ENVELOPE GENERATORS: Dual analog ADSR envelopes.
VOLTAGE CONTROLLED AMPLIFIERS: Dual analog VCAs.
ATTENUATORS: 3x bipolar voltage controlled attenuators with ring mod capability.
MULTIPLES: 2x4 parallel wired unbuffered mults.
SECOND LFO: Additional simple analog LFO useful for adding modulation to delay, filters and VCAs.
EXTERNAL PROCESSING: 1/4“ external audio input for processing guitars, drum machines, and more through Matriarch’s analog circuits.
OUTPUTS: Stereo ¼” and 3.5mm Eurorack level audio outputs.

Matriarch Specifications
TYPE: Semi-Modular Analog Synthesizer
SOUND ENGINE: 100% Analog
NUMBER OF KEYS: 49 Full-Size Keys
TYPE OF KEYS: Velocity-sensing with Aftertouch (Velocity and Aftertouch are not hard-wired – available via MIDI, KBD VEL OUT and KB AT OUT jacks)
OTHER CONTROLLERS: Pitch Bend, Mod Wheel, Variable Glide, Expression pedal in to CV out, and Sustain Pedal in
POLYPHONY: Monophonic, 2-Note Paraphonic, and 4-Note Paraphonic
SOUND SOURCES: 4x Analog Oscillators with Selectable Waveforms (Oscillators 2, 3, and 4 support Hard Sync), White Noise Generator, External Input jack.
MIXER: 6 input (5 eurorack level and 1 instrument level) DC coupled discrete mixer with asymmetrical clipping behavior
FILTERS: 24dB/Octave Low Pass Filter with Resonance, 24dB/Octave switchable Low Pass/High Pass Filter with Resonance. Configurable in parallel (HP/LP), stereo (LP/LP), and series (HP/LP).
MOD SOURCES: Analog Modulation Oscillator with selectable and patchable output (Sine, Saw, Ramp, Square, Stepped Triangle, Smoothed Random, Sample and Hold, Noise). Additional LFO (Tri, Square).
ENVELOPES: 2x Four-Stage ADSR with End of Envelope gate outputs
ATTENUATORS: 3x Bipolar Voltage Controlled Attenuators with Ring Mod capabilities
MULTS: 2x4 Parallel-wired Non-buffered Patch Points
VCAS: 2x discrete analog VCAs routed in stereo
EFFECTS: Stereo Analog Delay with Ping/Pong, MIDI and CV clock sync, voltage controlled Mix, and independent L/R delay times, feedback, and I/O
ARPEGGIATOR / STEP SEQUENCER: 256 Steps with up to 4 notes per step; 12 Sequence locations
PATCH POINTS: 90 x 3.5mm front and rear panels, 49 Inputs, 33 Outputs, 2x4 Parallel-wired Mults
PEDAL INPUTS: 1/4” Sustain, 1/4” Expression
AUDIO INPUT: 1/4” TS jack (Rear Panel)
AUDIO OUTPUTS: 2x 1/4” TS jacks for line level output (Rear Panel), 1/4” Headphone jack with dedicated level knob (rear panel), 2x 3.5mm Eurorack level outputs, 2x 3.5mm Delay outputs
MIDI I/O: 5-pin DIN In, Out, Thru; plus MIDI over USB (Rear Panel)
DIMENSIONS: 32” (81.28cm) Wide x 14 1/4” (36.19cm) Deep x 5 1/2” (13.97cm) High
POWER: Included Power Adapter 12V DC (positive tip), 2A, 100 to 240 Volts AC, 50/60Hz with screw-on barrel connector
WEIGHT: 24lbs. / 10.89kg
