Biamp Parle ABC 2500a
The Parlé ABC 2500a is an advanced all-in-one conferencing bar designed to deliver elite audio performance and effortless deployment in small to medium conference rooms. Powered by Biamp Audio Intelligence, it features a sophisticated 27-element microphone array with Beamtracking technology, enabling the system to actively follow and mix voices from anywhere in the room without manual configuration or zone mapping.
To maintain exceptional clarity, the ABC 2500a incorporates Acoustic Echo Cancellation and AI-based Noise Reduction, filtering out disruptive background sounds such as HVAC hum and keyboard noise. Two integrated smart speakers use distortion compensation and dynamic bass enhancement to deliver rich, full-range audio optimized for speech intelligibility.
GENERAL
Height: 3.9 inches (100 mm)
Width: 37 inches (940 mm)
Depth: 2.5 inches (64 mm)
Weight: 9.6 lbs (4.4 kg)
ENVIRONMENTAL
Ambient Operating Temperature Range: Operating Temperature: 32 - 104° F (0 - 40° C)
Humidity: 0-90% (non-condensing)
Altitude: 0-10,000 ft (0-3000m) MSL
POWER
Power: Continuous Rated Power (6 dB crest factor, HPF @ 60 Hz): 20W
Power Sources:
• USB-C: 60W
• External Power Supply: 100-240VAC 50/60Hz (12VDC, 4.74A)
CONTROLS & INDICATORS
Control Interfaces:
• USB 3.0: 1x Type C
• Assistive Listening Feed: 1x 3.5mm mono balanced
LOUDSPEAKER
Beamwidth: Nominal Beamwidth (H x V): 180° x 180°
Transducers: 2x 2.5 inch (60 mm) full range
Sensitivity: (@ 1m, 2.83V): 84 dB
AUDIO
Audio:
• Interfaces
• USB 3.0: 1x Type C
• Assistive Listening Feed: 1x 3.5mm mono balanced
Microphone:
MICROPHONES
• Microphone Technology: 27-Element Digital Array
• Frequency Response (100 Hz - 8 kHz): -10dB
• Polar Pattern: Active Beamformed
• Pickup Range (25dBA noise floor): > 23 feet (7 m)
• SNR (@ 1kHz, 94dB SPL, A-Weighted): 69 dB
• Maximum SPL (@ 1kHz, THD < 10%): 130 dB
• Indicators: Mute Indicator (Green/Red/Off LEDs)
• Sensitivity (@ 1Pa): > -37dBFS ± 1dB
• Microphone Data Rate Output: 48 kHz
• Audio Processing: AEC (Acoustic Echo Cancellation)
• Noise Reduction: AI Filter
Impedance: Nominal Impedance: 4Ω
THD+N: THD (@ 1kHz): < 0.2%
Frequency Response: (57 Hz - 20 kHz): -10 dB
SPL: Rated Maximum SPL (@ 1m): 90 dB (continuous), 96 dB (peak)
Sampling Rate: 48 kHz
Microsoft Teams: Microsoft Teams Certified
Zoom: Zoom Certified
Barco: Barco Certified
Certifications:
• FCC Part 15B (USA)
• CE Marked (Europe)
• UL and C-UL listed (USA and Canada)
• RoHS Directive (Europe)
