Biamp Parle VBC 2800
The Parlé VBC 2800 elevates conferencing performance with a sophisticated combination of Audio Intelligence and Video Intelligence technologies. Its 27-element microphone array uses Biamp Beamtracking™ to follow multiple talkers naturally, allowing participants to move freely while maintaining clear, consistent pickup. Integrated Acoustic Echo Cancellation and AI Noise Reduction work together to improve speech intelligibility and ensure remote attendees hear only what matters.
For video, the VBC 2800 features a dual-camera architecture consisting of a 50 MP ultrawide lens and an 8 MP wide-angle ePTZ module. Together, they deliver a 120° horizontal field of view and up to 16x digital zoom, enabling the system to capture participants at long conference tables with remarkable detail. Intelligent auto-framing dynamically switches cameras to present the most appropriate view, creating a more natural and engaging meeting experience.
GENERAL
Height: 3.9 inches (100 mm)
Width: 37 inches (940 mm)
Depth: 2.5 inches (64 mm)
Weight: 9.6 lbs (4.4 kg)
ENVIRONMENTAL
Ambient Operating Temperature Range: 32 - 104° F (0 - 40° C)
Humidity: 0-90% (non-condensing)
Altitude: 0-10,000 ft (0-3000m) MSL
POWER
Power SOURCES:
• USB-C: 60W
• External Power Supply: 100-240VAC 50/60Hz (12VDC, 4.74A)
LOUDSPEAKER
Beamwidth: Nominal Beamwidth (H x V): 180° x 180°
Transducers: 2x 2.5 inches (60 mm) full range
Sensitivity: (@ 1m, 2.83V): 84 dB
VIDEO
Supported Resolution:
• 720p @ 30 fps
• 1080p @ 30 fps
• 2160p @ 30 fps
Camera:
• DUAL CAMERA SYSTEM
• Ultrawide Lens
• Wide Angle Lens
Physical Interfaces:
• USB 3.0: 1x Type C
• Analog Audio Input 1x 3.5mm mono unbalanced
• Assistive Listening Feed: 1x 3.5mm mono balanced
Diagonal Field of View:
• ULTRAWIDE LENS: 150°
• WIDE ANGLE LENS: 110°
Horizontal Filed of View:
• ULTRAWIDE LENS: 122°
• WIDE ANGLE LENS: 86°
Verticle Field of View:
• ULTRAWIDE LENS: 88°
• WIDE ANGLE LENS: 69°
Image Sensor:
• ULTRAWIDE LENS: 8 Megapixel
• WIDE ANGLE LENS: 50 Megapixel
Focus Distance:
• Minimum Focus Distance: ULTRAWIDE LENS: 100 cm
• WIDE ANGLE LENS: 300 cm
Digital Zoom:
Max Zoom:
• ULTRAWIDE LENS: 3x
• WIDE ANGLE LENS: 16x
Lens Cap: Automated Privacy Shutter
Positioning:
• Autoframing capabilities
• Electronic Pan/Tilt/Zoom
• UVC controlled
Indicators: Camera Active Indicator (White/Off LED)
Microphone: Microphone Technology: 27-Element Digital Array
Impedance: Nominal Impedance: 4Ω
THD+N: (@ 1kHz): < 0.2%
Frequency Response: (57 Hz - 20 kHz): -10 dB
SPL: Rated Maximum SPL (@ 1m): 90 dB (continuous)
Sampling Rate: 48 kHz
CERTIFIED SOLUTIONS
Zoom: Zoom Certified
COMPLIANCE
Certifications:
• FCC Part 15B (USA)
• CE Marked (Europe)
• UL and C-UL listed (USA and Canada)
• RoHS Directive (Europe)
• REACH (Europe)
