MARTIN WISMAN MTX 808

Šifra: 7003
Na stanju
107.880,00 rsd
89.900,00 rsd (Bez PDV-a)
Iznos rate:
Prikazana cena je za komad.

Garantujemo najnižu cenu!

Količina

Ukoliko želite da platite na rate kreditnom karticom, molimo Vas da izaberete broj rata.

Važi za kreditne kartice logo_banka

Broj rata:

Dostupno u prodavnici:
  • Svetogorska 9, Beograd
  • Centralni magacin
Prijavi povoljniju cenu Obavesti me ako cena padne Postavi pitanje
Opcija:

8 x 8 Audio Matrix & Paging System - Weekly Timer / SD / 10 Zone / monitor / Power Sequencer
* The 8 zone matrix & paging controller MTX 808 which is cater for multi-zone paging and multi-sources selection system. It offers a complete solution for multi-zone, multi-functional venues like entertainment places, large hotel, sports or gym centers, shopping mall and airport etc.* The MVT 8000B offers direct connection of up to 8 music source inputs (4 RCA inputs and 4 line/mic inputs), 8 remote control panels, 2 remote paging consoles and one microphone input, all of these inputs can be freely allocated into different 8 zone outputs simultaneously.*

8 x 8 Audio Matrix & Paging System - Weekly Timer / SD / 10 Zone / monitor / Power Sequencer

* The 8 zone matrix & paging controller MTX 808 which is cater for multi-zone paging and multi-sources selection system. It offers a complete solution for multi-zone, multi-functional venues like entertainment places, large hotel, sports or gym centers, shopping mall and airport etc.
* The MVT 8000B offers direct connection of up to 8 music source inputs (4 RCA inputs and 4 line/mic inputs), 8 remote control panels, 2 remote paging consoles and one microphone input, all of these inputs can be freely allocated into different 8 zone outputs simultaneously.
* One remote paging console and 3 different remote control panels are available when extension control, multi-zone paging and multi-sources routing is needed.
* The controller is also expandable to 32 zones via a simple link cable to cascade 4 units together into 8x32 matrix system.
* With digital LCD display of program/local input selection and monitor selection, and LED indication for monitor output level, microphone priority and busy.
* Each channel input is provided with individual mic, music, master volume control, each line and paging console input with gain control, microphone input with gain, bass and treble tone control. Monitor volume control as well as provided.
* Each channel output is provided with individual gain, bass and treble tone control, a gain control is also provided for each channel's remote wall control.
* 8 channel voice alarm contact closure to override all music and paging system during fire alarm state.
* Alert, evacuation and EMC three kinds of pre-recorded chimes are provided with tone control.
* Both paging consoles and remote control panels connect via universal and industrial standard CAT 5 cable.
* 4 swift keys for direct all channel BGM and paging access.
* AC 120V & 240V input with voltage switch and DC 24V operation.
* 5 levels of priority from high to low are: microphone 1, fire alarm input, remote paging console, remote control panel and background music.

Specifications



Model

MTX 808

Line Input

Line 1-8: 300mV/10KΩ

Microphone 1

5mV/600Ω

Remote Paging Station

500mV/10KΩ

Output

0.775V/600Ω

Frequency Response

MIC 80Hz~18KHz +1/-3dB line: 0Hz~20KHz +1/-3dB

Microphone S/N Ratio

>65dB

Line S/N Ratio

>85dB

Degree Of Separation

>40dB

Crosstalk

>65dB

THD

<0.07%

Indicator

Power, Mic1, paging busy & monitor output

Priority

Mic1, voice alarm, local mic paging, remote zone paging, line 8, line 1-7

Communication Speed

4800bps

Communication Port

RJ45

Communication Protocol

RS485

Power Consumption

20W

Power Supply

~110V/60Hz or ~230V/50Hz & DC 24V

DC Input

DC 24V

Dimensions

484×400×132mm

Weight

6Kg
