Sennheiser EW-DX EM 2 DANTE (Q1-9) - Baza
Two-channel digital half-rack (9,5") Dante®-enabled receiver for use with Evolution Wireless Digital handheld, bodypack and tablestand transmitters. Extended 88 MHz switching bandwidth, intermodulation-free operation [intermodulation-free equidistant channel spacing] for up to 293 channels with secure AES 256 encryption and redundant power supply via Power over Ethernet (PoE).
Features
• Two-channel digital half rack (9.5") with Dante® in rugged metal housing
• Up to 88 MHz switching bandwidth
• Flexible network modes: single cable (Control, Dante®, PoE), split mode (Control + PoE and Dante® daisy chain), redundancy mode (Control + PoE, Dante® Prim, Dante® Sec)
• Low latency of 1.9 ms wireless transmission thanks to proprietary Sennheiser Performance Audio Codec (SePAC)
• 134 dB input dynamic range - no need to set gain on your wireless transmitters at all, thanks to proprietary Sennheiser Performance Audio Codec (SePAC)
• Equidistant channel spacing to easily allocate intermodulation-free channels: Standard Mode with 600 kHz spacing for up to 146 channels; Link Density (LD) Mode with 300 kHz spacing for up to 293 channels
• Network enabled for expanded remote control with Sennheiser Control Cockpit, Wireless System Manager (WSM - Available in mid-2023) and 3rd party media control systems via plug-in
• Power over Ethernet (PoE IEEE 802.3af Class 3)
• Ethernet connectivity (IPv4 and IPv6)
• Secure transmission of confidential content using AES 256 encryption
• AutoScan-feature quickly scans your environment and deploys frequencies with equidistant channel spacing - even without RF knowledge
• Link Quality Indicator (LQI) showing the quality of the links seperate to the RF levels
• Remote control via Smart Assist App over Bluetooth® Low Energy (BLE) at distances up to 25 meters (Available in late 2023)
• Clear and easy focused user interface with OLED display, jog wheel navigation and control buttons
• Selective headphone output with volume control on front panel
• Extended menu settings such as custom frequency list, selectable sync parameter and walk test
• External PSU 12V/1A
• Worldwide usage (specific frequencies subject to local RF regulations)
Tech Specs
Product
Total harmonic distortion (THD): ≤ -60 dB for 1 kHz @ -3 dBfs input level
Frequency Specifications
Audio frequency response: 20 Hz - 20 kHz (-3 dB) @ 3 dBfs
Acoustic Properties
Dynamic range (>): 134 dB
Ambient Conditions
Operating relative humidity (≤ %): 5 - 95 % (non-condensing)
Operating temperature (C): -10 °C - +55 °C (14 °F - 131 °F)
Dimensions
Height (mm): 75
Length (mm): 405
Master carton height (mm): 258
Master carton length (mm): 430
Master carton weight (g): 610
Master carton width (mm): 435
Weight (g): 2768
Width (mm): 360
Package Depth (mm): 350
Package Height (mm): 73
Package Weight (g): 2690
Package Width (mm): 405
