POWERMATE 1600 MK3
All the function groups of the PowerMate are 100% professional in terms of their design and specification. First comes the mixing section, where you will fi nd high-quality, discrete microphone preamps, new, dustproof ALPS faders (specially developed for the PowerMate) with very high attenuation even in the HF range, 48V phantom power switchable to the channels in groups of six and a dynamic range that would put most dedicated professional mixers to shame. AUX 3+4 are separately switchable pre/post fader. Then come the ultra-effi cient Class H power amplifi ers, which now deliver 2 x 700 W into 4 Ohms (PM 1000 and 1600). They are equipped with dynamic limiters, an extensive range of protections and the LPN fi lter for clearly improved bass performance. Finally in the effects section, the two digital effects processors offer 99 studio quality presets each and are individually foot-switchable. On top of these, there are many other useful features designed to solve special problems, such as the two feedback filters, the vocal voicing fi lter and the standby switch. This is a powered mixer that can also be used as a pure mixer, with power amplifi ers every bit as good as dedicated 19“ concert sound amplifi ers, and studio quality effects specially optimised for live performance. Housed in a robust case with a sturdy metal lid, the PowerMate is manufactured in Germany to the highest standards. Nothing else sounds like it. Nothing else performs like it. And nothing is as reliable.
Specifications:
-
Channels (Mono + Stereo) 12 + 4 Auxiliaries (MON, FX, AUX) 2 Pre, 2 Post, 2 Pre/Post switchable
Maximum Midband Output Power,1 kHz, THD=1%, Dual Channel
into 2.66 Ohms 2 x 1350 W
into 4 Ohms 2 x 1000 W
into 8 Ohms 2 x 600 W
Rated Output Power,THD=0.1%, Single Channel
into 4 Ohms 2 x 900 W
into 8 Ohms 2 x 450 W
Maximum Output Voltage of power amplifier, no load 74 Vrms THD at 1kHz, MBW=80kHz MIC input to Master A L/R output, +16 dBu, typical < 0.005% POWER AMP INPUTS to Speaker L/R output < 0.075%DIM 30, power amplifier, 60Hz, 7kHz 0.05%
IMD-SMPTE, power amplifier, 60Hz, 7 kHz 0.015%
CMRR, MIC input, 1 kHz> 80 dB
Equivalent Input Noise, MIC Input, A-weighted, 150 Ω-130 dBu
Signal/Noise-Ratio, power amplifier, A-weighted, 4 Ohms 105 dB
Output Stage Topology, amplifier Class D
Equalization LO Shelving +/- 15 dB / 60 Hz. MID Peaking, mono inputs+/- 15 dB / 100 Hz .. 8 kHz .MID Peaking, stereo inputs +/- 12 dB / 2.4 kHz HI Shelving +/- 15 dB / 12 kHz Master EQ, 11-band (63, 125, 250, 400, 1k, 1.6k, 2.5k, 4k, 6.3k, 12k Hz) +/- 10 dB / Q = 1.5-2.5
Filter LO-CUT, mono inputs f=80 Hz, 18 dB/oct. VOICE FILTER, mono inputs. FEEDBACK FILTER, MON1/2 70 Hz .. 7 kHz, Notch, -9 dB
Speaker Processing LPN, switchable
Display High Contrast OLED
Effects Type Dual stereo 24/48-bit multi effects processors
Effects presets 100 Factory + 20 User, Tap-Delay
Remote Control Footswitch, MIDI
Digital Audio Interface Channels 4 In / 4 Out AD/DA Conversion 24bit Sampling Rate 44.1 / 48 / 88.2 /96 kHz PC Interface USB 2.0, Female Type B
MIDI Interface 5-pin DIN connector, In / Out
Output Power Control Adjustale RMS Limiter
Protections Mixer Outputs (Relay controlled) MON1, MON2, MASTER A, Amplifier, Audio Limiters, High Temperature, DC, HF, Short Circuit, Peak Current Limiters, Turn-On-Delay, Switching Mode Power Supply (µPC controlled), Inrush Current Limiters, Mains Over/Under Voltage, Mains Over Current, High Temperature
Cooling Continuous speed controlled Fans
Phantom Power, switchable in groups 48V DC
Power Requirements (SMPS with auto range mains input) 100 V .. 240 V AC, 50 Hz .. 60 Hz
Power Consumption, at 1/8 maximum output power, 4 Ohms 450 W
Safety Class 1
Ambient Temperature Limits +5 °C .. + 40 °C / 40 °F .. 105 °F
Dimensions (W x H x D), mm, with lid,663.5 x 164.5 x 498.5
Weight Net weight, without lid 15.0 kg. Net Weight, with lid 17.0 kg. Shipping Weight 20.0 kg
Warranty 36 Month
Device in rated condition, Unity Gain (MIC Gain 20 dB), all faders position 0 dB, all pots in mid position, master fader +8dB, LPN +12dB, amplifier load 8 ohms, dual channel, Mains voltage 230V/50Hz.
