Innovation
ARX introduces the all-new ZoneMIX multimedia, multi-channel mixer.

Great Features

• Wireless audio, USB and MiniJack inputs!


• Plus 2 x Balanced Low Noise Microphone pre-amps


• Plus a stereo Line In channel


• Plus all Inputs can be switched to Stereo Zone 1 or 2, or Both


• Plus Outputs can be switched to Mono for distributed systems

AC Power
The ZoneMIX is available as an AC specific 100 to 120V AC model or a 220 to 240V AC model. AC power is connected to the unit via a standard three pin IEC connector, with built-in fuse.

Microphone Inputs: Electronically Balanced on XLR Connectors, switchable to Mono

Stereo Line Inputs: Line level inputs on RCA Connectors

Input Gain: Variable 0dB to 50dB on Mic/Line channels by rear panel trim control, plus Mic/Line input switch (–20dB)

Channel Level: Infinity to +6dB Gain

Frequency Response: 20-20KHz ± 1dB

Distortion: Below .005% 100Hz to 10KHz

Master Outputs: Electronically Balanced XLR, switchable to Mono

Master Outputs Signal/Noise: -90dB unweighted.

Max Output Level: +20dB

Wireless Audio Receiver Specifications

USB Specifications

Input Connector USB type B port

Codec 24 bit High Resolution, 44.1 and 48K, program dependent

USB Power Operating current via USB Port 80mA

With its superb audio quality, headroom to spare, and intuitive interface, the ARX ZoneMIX is the total solution to today’s install requirements.
