Specifications
1600W
Nominal Power Rating
98dB
Sensitivity
5in
Voice coil diameter
Nominal Diameter530mm/21in
Nominal Power Rating1600W
Continuous Power Rating3200W
Sensitivity98dB
Rated Impedance8Ω
Frequency Range30Hz-3000Hz
Voice coil diameter (mm)125mm
Voice coil diameter (in)5in
Chassis TypeCast aluminium
Magnet TypeNeodymium
Voice coil materialRound copper
Former MaterialGlass fibre
Cone materialCarbon fibre loaded paper
Surround MaterialCloth-sealed
SuspensionDouble
Xmax9mm/0.35in
Gap Depth12mm/0.47in
Voice coil winding width30mm/1.18in

Small Signal Parameters
Sd1661.90cm2/257.59in2
Fs32.20Hz
Mms344.10g/12.14oz
Qms5.819
Qes0.339
Qts0.320
Re5.57Ω
Vas276.70L/9.77ft3
BI33.85Tm
Cms0.07mm/N
Rms11.98kg/s
Le (at 1kHz)2.25mH
Mounting Information
Mounting slot dimensions12.5mm x 8.5mm/0.49in x 0.33in Ø
Mounting slot PCD520mm-528mm/20.5in-20.8in
Number of mounting slots8
Overall Depth254mm/10in
Overall Diameter (mm)550mm
Overall Diameter (in)21.65in
Cut-out diameter492mm/19.37in
Unit Weight12.8kg/28.2lb
