For Boardroom A/V to Live Music
Portable Powered Loudspeaker System
3-Channel Mixer with 3-Band EQ
Two Mic/Line Preamps with 48V
Hi-Z Input for Instruments
Dedicated Stereo Line-Level Channel
Built-In Limiter for System Protection
Mic Stand Integration System
Lightweight at 7.6 lb
Includes Power Cord
Key Specs
| Speaker Configuration |
1x Full-Range Loudspeaker
|
| Number of Input Channels |
3 (2 x Mono, 1 x Stereo)
|
| Amplifier Power Rating |
150 W
|
| Audio I/O |
1x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line/Hi-Z Input
1x Combo XLR-1/4" TRS Mic/Line Input
1x Combo XLR-1/4" TRS Line Input
1x Stereo RCA TS Input
1x XLR 3-Pin Male Mic/Line Thru
|
Portable PA System
| Speaker Configuration |
1x Full-Range Loudspeaker
|
| Number of Input Channels |
3 (2 x Mono, 1 x Stereo)
|
| Amplifier Power Rating |
150 W
|
| Amplifier Class |
Class-D
|
Speakers
| Full-Range Driver |
5.25" / 133.35 mm Cone
|
| Magnet |
Neodymium
|
Signal Processing
| Input Pad |
No
|
| EQ |
Contour:
±15 dB at 12 kHz (on Master)
±15 dB at 2.5 kHz (on Master)
±15 dB at 100 Hz (on Master)
|
Performance
| Frequency Response |
100 Hz to 17.5 kHz -3 dB
|
| Frequency Range |
60 Hz to 22 kHz -10 dB
|
| Maximum SPL |
120 dB (Peak)
|
| I/O Impedance |
Mic Input:
3 Kilohms (Balanced)
Hi-Z Input:
20 Kilohms (Balanced)
Line Input:
10 Kilohms (Balanced)
|
| THD |
0.05%
|
| Protections |
AC Fuse, Output Limiter
|
Connectivity
| Audio I/O |
1x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line/Hi-Z Input
1x Combo XLR-1/4" TRS Mic/Line Input
1x Combo XLR-1/4" TRS Line Input
1x Stereo RCA TS Input
1x XLR 3-Pin Male Mic/Line Thru
|
| Phantom Power |
+48 V (Switchable)
|
Power
| AC Input Power |
100 to 240 VAC, 50 / 60 Hz
|
| AC Power I/O |
IEC Input
|
Physical
| Transport Options |
Handle (Top)
|
| Mounting |
1 x Mic Stand Socket (Bottom)
|
| Construction Material |
Polypropylene
|
| Environmental Protection |
No
|
| Operating Temperature |
32 to 104°F / 0 to 40°C
|
| Dimensions |
11.2 x 8 x 6.8" / 28.4 x 20.3 x 17.3 cm
|
| Weight |
7.6 lb / 3.4 kg
|
