Pioneer XY-218S
Â
Dual 18” bass reflex subwoofer
Features:
• High-power subwoofer with two 18-inch, low-frequency driver.
• Capable of reproducing deep bass as low as 32 Hz without distortion.
• Strong pillars installed in the cabinet ensure rigidity against the most powerful bass.
• Requires an active crossover to set the necessary frequency range (presets can be provided from Pioneer for combinations using the Pioneer XY-152 and XY-122).
• NL4 INPUT and LINK OUT connections as standard.
• Robust enclosure made from premium multi-laminate birch plywood.
Hardware
Enclosure Type: Dual driver, reflex-loaded subwoofer
Rigging and Hardware:
• 8 × flush handles (4 left/4 right),
• 8 × rubber feet (bottom and left) and 4 ×mating recesses (top),
• 16 × M8 holes with pre-inserted bolts for 4 × castors on rear
Grille: Hex punched steel
Enclosure: 18 mm (0.7 inch) birch plywood
Finish: Impact-resistant, Black semi-matt textured
System data
Frequency response: 32 Hz to 150 Hz
Sensitivity (1W/1m): 102 dB (half space)
Nominal Impedance: 4 Ω
Loudspeaker data
Power Handling: 1600 W RMS, 3200 W Program
Power Handling AES: 134 dB cont., 140 dB peak (half space)
Transformer taps: 2 Ă— 18 inch (460 mm) LF cone drivers
Dispersion: 2 × Neutrik SpeakON™ NL4
Dimensions / Weight
Dimensions ( W x H x D): 1164 Ă— 558 Ă— 745 mm (45.8 Ă— 22 Ă— 29.3 inch)
Weight: 93 kg (205 lbs)
