API AUDIO 527A
Šifra: 21593
Taking its place alongside the API Audio family of VCA-based compressors, the 527A is a 500-series compressor/limiter module sporting selectable feedforward (New) and feedback (Old) compression modes. Along with selectable hard- or soft-knee compression and the patented THRUST circuit for extra punch in the low frequencies, the 527A is a versatile studio compressor.
| Kategorija | Parametar | Opis / Vrednost |
|---|---|---|
| SRCE UREĐAJA | Tehnologija | Potpuno diskretna (2510 & 2520 op-amps) |
| Format | Modul 500 serije (1 slot) | |
| DINAMIKA | Threshold | od +10 dBu do -20 dBu |
| Ratio | od 1:1 do beskonačno (Limiting) | |
| Attack | 1ms do 25ms (varijabilno) | |
| Release | 0.3s do 3s (varijabilno) | |
| KARAKTER | Compression Modes | Old (Feedback) / New (Feed-forward) |
| Knee | Hard (oštro) / Soft (zaobljeno) | |
| Sidechain Filter | THRUST® (zaštita dubokih tonova) | |
| PERFORMANSE | Frekvencijski raspon | 20Hz - 50kHz (+0, -0.5dB) |
| Izlazni Gain | od -∞ do +10 dB | |
| Bypass | True Hardware Bypass (relejni) | |
| KONEKCIJA | Impedansa | Ulaz: 30kΩ / Izlaz: <75Ω |
| Potrošnja | ±16V DC @ 130mA |
Opis nije dostupan
