Cranborne Audio Brick Lane 500
Brick Lane 500: The Modal Compression Revolution
500 Series analogue PWM Compressor with 6 operating modes and variable Stress control for harmonically-enriched compression effects.
A Technological Breakthrough in Dynamics Processing
The Brick Lane 500 represents a quantum leap in analogue compression — a fully-analogue PWM Compressor that transcends traditional dynamics control methodologies through its revolutionary Modal PWM Compression architecture.
Technical Data
Test Signal Path: APx555 (Line Out) - Input - Line Output - APx555 (Line In)
Max Input Level: +24dBu (<0.003% THD)
Max Output Level: +26.5dBu (<0.003% THD)
Frequency Response: ±0.5dB, 2 Hz - 80 kHz
Noise Floor: <-100dBu (unweighted)
Dynamic Range: >118dB
Input Impedance: Line = 43 kOhms
Output Impedance: Line = 150 Ohms
Current Draw: 140mA per rail - typical use case, 160mA per rail - max
Compression Specifications
Compression
Compression Element: Pulse Width Modulation
Switching Frequency: 250kHz
Distortion (THD)
• 0dB Gain Reduction - <0.0006% THD+N, <0.00025% THD
• 5dB Gain Reduction - <0.00085% THD
• 10dB Gain Reduction - <0.00085% THD
• 20dB Gain Reduction - <0.00085% THD
Harmonics (Stress Control): <20% THD depending on conditions
Frequency Range: 200Hz - 6.2kHz
Sidechain Detection HPF: Selectable - 60Hz, 100Hz, 200Hz, OFF
Minimum Attack Time (Standard): 6 nanoseconds (2 microseconds processing delay)
Minimum Attack Time (POLISH mode with Analogue Lookahead enabled): 6 nanoseconds (0 nanoseconds processing delay @ 20kHz)
Environmental
Operating Temperature: +1 to 35 degrees Celsius
Storage Conditions: -20 to 50 degrees Celsius
Dims/Weights
Unit
Width: 170mm (6.6”)
Height: 31mm (1.2")
Depth: 133mm (5.2")
Unit Weight: 0.4kg (0.9 lbs)
Shipping carton
Width: 250mm (9.5")
Height: 200mm (7.8")
Depth: 100mm (4")
Carton Weight: 0.5kg (1.1lb)
