8 Channel Mic Preamp with HMX & IRON
ASP800 is an audio powerhouse designed with expandability in mind, making it the perfect addition to your audio interface. Upgrade your current setup with 8 channels of Audient’s Console mic preamps, 8 line inputs, class leading converters, two JFET D.I’s and two Retro Channels with powerful tone control.
Microphone Preamplifiers
MIC GAIN:0 to 70 dB (extra gain stage for more!)
SWITCHABLE PAD:-15 dB (all channels front panel switchable)
LINE GAIN:-10 to 60 dB (-25 to 45 dB inc. PAD)
PHANTOM POWER:48V ±4V @ 10mA / channel
MIC EIN:<-127.0 dBu
CMRR:>80 dB @ 100Hz to 2kHz
MAXIMUM INPUT LEVEL:+20 dBu (+35 dBu with PAD)
INPUT IMPEDANCE (Mic):>2k Ω balanced (approx. 2.2k Ω)
INPUT IMPEDANCE (Line):>8k Ω balanced (approx. 8.6k Ω)
FREQUENCY RESPONSE:±0.5 dB 10Hz to 100kHz @ min. gain
CROSSTALK:< -90 dBu 10Hz to 10kHz
THD+N @ 0dBu (1kHz):<0.003% (-90.5 dBu) mostly 3rd harmonic
SNR:>90 dB @ min. gain
XLR COMBI FEMALE:Pin 2 (Hot), Pin 3 (Cold) & Pin 1 (Shield)
1/4” TRS JACK:Tip (Hot), Ring (Cold) & Sleeve (Shield)
Discrete JFET D.I
D.I GAIN:0 dB unity gain (0 to 70 dB)
MAXIMUM INPUT LEVEL:+17 dBu
INPUT IMPEDANCE:1Meg Ω unbalanced
FREQUENCY RESPONSE:±0.5 dB 10Hz to 50kHz
THD+N @ 0dBu (1kHz):<0.01% (-80 dBu) mostly 2nd & 3rd
SNR:>85 dB @ min. gain
1/4” JACK:Tip (Hot) & Sleeve (Shield)
Balanced Analogue Line Outputs
MAXIMUM OUTPUT LEVEL:+22 dBu
OUTPUT IMPEDANCE:<200Ω ground sensing, <100Ω unbalanced
A-D Converter
CHIPSET:Burr-Brown PCM4204 24-bit PCM
DIGITAL REFERENCE LEVEL:Selectable via Rear Panel, 0 dBFS = +18 dBu (iD22 Professional), 0 dBFS = +12 dBu (iD14 Prosumer)
FREQUENCY RESPONSE:±0.1 dB 20Hz to Fs/2 (Nyquist)
CROSSTALK:<-110 dBFS @ 1kHz & <-90 dBFS @ 10kHz
THD+N @ -1 dBFS (1kHz):0.0015% (-96.5 dB)
THD+N @ -6 dBFS (1kHz):0.0009% (-101 dB)
DYNAMIC RANGE:113.5 dB un-weighted, 116.0 dB A-weighted
PEAK LED LINEUP:-2 dBFS (moves with reference level)
SIGNAL LED LINEUP:-38 dBFS (moves with reference level)
Digital Output
ADAT 8 CHANNELS SMUX:44.1 to 96.0 kHz
CLOCK:Internal Crystal or External Source
WORDCLOCK INPUT:75Ω BNC – switchable 75Ω termination
Power Supply
LOW NOISE SHIELDED LINEAR PSU FANLESS, QUIET OPERATION:CUSTOM TRANSFORMERS, 35W Maximum Consumption
INTERNAL D.C POWER RAILS:±15V, +48, +30V & +9V
SWITCHABLE MAINS VOLTAGE:100, 120, 220 or 230Va.c
FUSE:200mA (UK) or 315mA (US), Time Delay (T) Slow-Blow Type
Weight
4.5kg
Dimensions
1RU, 482mm x 286.5mm x 44mm
