Neumann M 150 TUBE - Lampaški mikrofoni
A LEGEND PERFECTED
The M 150 Tube is a unique small diaphragm condenser microphone for orchestral recordings, based on the legendary Neumann M 50. The M 150 uses a titanium capsule flush mounted in a small sphere to create an omni pattern which becomes directional at higher frequencies. An innovative transformerless tube circuit ensures a vivid sound with low noise.
Acoustical operating principle: Pressure transducer
Directional Pattern: Omnidirectional
Frequency Range: 20 Hz ... 20 kHz
Sensitivity at 1 kHz into 1 kohm: 20 mV/Pa
Rated Impedance: 50 ohms
Rated load impedance: 1 kohms
Equivalent noise level, CCIR¹⁾: 28 dB
Equivalent noise level, A-weighted¹⁾: 15 dB-A
Typical SPL (tube characteristic) for K<0.5%²⁾: 114 dB
Typical SPL (tube characteristic) for K<5%²⁾": 134 dB
Signal-to-noise ratio, CCIR (re. 94 dB SPL)¹⁾: 66 dB
Signal-to-noise ratio, A-weighted (re. 94 dB SPL)¹⁾: 79 dB
Maximum output voltage: 8 dBu
Dynamic range of the amplifier, DIN/IEC 651, for THD < 0.5%²⁾: 99 dB
Dynamic range of the amplifier, DIN/IEC 651, for THD < 5%²⁾: 119 dB
Power supply: N 149 A
Matching connector: Microphone: DIN 8 F, Power Supply: XLR 3 F
Weight: 800 g
Diameter: 78 mm
Length: 165 mm
