Features
• Super-cardioid/lobar pick-up pattern
• Very natural sound
• Undistorted off-axis sound
• Exceptionally low inherent self-noise
• Extremely low distortion
• Transformerless and fully floating balanced output
• High output signal
• Rugged metal housing
• Non-reflective Nextel® coating
• Extremely weather-proof due to RF circuit
• Ideal for camera mounting due to compact design
• Timbrally identical with the other 8000-series microphones for optimum aural compatibility

Product
Transducer principle: RF condenser microphone
Polar pattern: Supercardioid, Lobar

Frequency Specifications
Frequency response: 50 - 25000 Hz
Audio frequency response: 50 - 25,000 Hz

Acoustic Properties
Equivalent noise level (db): A-weighted 11 dB(A) CCIR-weighted 23 dB
Pick-up pattern: super-cardioid/lobar
Max. sound pressure level: 129 dB SPL

Connectivity
Connection: Wired

Inputs/Outputs
Audio output: XLR-3M balanced, transformerless, floating

Ambient Conditions
Operating temperature (C): -10 °C to 60 °C (14 °F to 140 °F)

Battery & Power
Battery included: N
Phantom power: 48 V ±4 V (P48, IEC 61938)
Charging current (mA): 3.3 mA
Phantom powering: 48 V +/- 4 V

Electrical Properties
Sensitivity: -24 dBV/Pa (63 mV/Pa)
Nominal impedance: 25 Ω
Min. terminating impedance: 2 kΩ

Dimensions
Dimensions: diameter 19 mm, length 175 mm (145 mm excluding XLR module)
Height (mm): 82
Length (mm): 245
Weight (g): 501
Width (mm): 170
Product height: 82
Product length: 245
Product weight (g): 80
Product width: 170
