Neumann TLM 193 - Mikrofon sa velikom dijafragmom
SIMPLY BEAUTIFUL & BEAUTIFULLY SIMPLE
The TLM 193 is a reference class studio microphone for project studios and all applications that do not require selectable polar patterns. The TLM 193 is a switchless design with a fixed cardioid pattern and a remarkably even frequency response. This makes it extremely easy to use: Just aim it at the source and press record.
Acoustical operating principle: Pressure gradient transducer
Directional Pattern: Cardioid
Frequency Range: 20 Hz ... 20 kHz
Sensitivity at 1 kHz into 1 kohm: 18 mV/P23 mV/Pa = –32.5 dBV ± 1 dBa
Rated Impedance: 50 ohms
Rated load impedance: 1 kohms
Equivalent noise level, CCIR¹⁾: 21 dB
Equivalent noise level, A-weighted¹⁾: 10 dB-A
Maximum SPL for THD 0.5%²⁾: 140 dB
Signal-to-noise ratio, CCIR (re. 94 dB SPL)¹⁾: 73 dB
Signal-to-noise ratio, A-weighted (re. 94 dB SPL)¹⁾: 84 dB
Maximum output voltage: 13 dBu
Supply voltage (P48, IEC 61938): 48 V ± 4 V
Current consumption (P48, IEC 61938): 3 mA
Matching connector: XLR 3 F
Weight: approx. 480 g
Diameter: 49 mm
Length: 175 mm
Opis nije dostupan
