Neumann TLM 49 - Mikrofon sa velikom dijafragmom
CLASSIC SOUND FOR TODAY’S ENGINEERS
The TLM 49 brings back the vintage tone of Neumann’s post-war classics. The TLM 49 uses the same K 47 capsule and the iconic large headgrille design of Neumann’s legendary M 49, but instead of electron tubes the TLM 49 relies on trouble free FET circuitry with a special sound design for smooth vocals and acoustic instruments with timeless elegance.
Acoustical operating principle: Pressure gradient transducer
Directional Pattern: Cardioid
Frequency Range: 20 Hz ... 20 kHz
Sensitivity at 1 kHz into 1 kohm: 13 mV/Pa = –38 dBV ± 1 dB
Rated Impedance: 50 ohms
Rated load impedance: 1 kohms
Equivalent noise level, CCIR¹⁾: 23 dB
Equivalent noise level, A-weighted¹⁾: 12 dB-A
Maximum SPL for THD 0.5%²⁾: 110 dB
Signal-to-noise ratio, CCIR (re. 94 dB SPL)¹⁾: 71 dB
Signal-to-noise ratio, A-weighted (re. 94 dB SPL)¹⁾: 82 dB
Maximum output voltage: -1 dBu
Supply voltage (P48, IEC 61938): 48 V ± 4 V
Current consumption (P48, IEC 61938): 3.2 mA
Matching connector: XLR 3 F
Weight: 825 g
Diameter: 78 mm
Length: 165 mm
Opis nije dostupan
