Neumann U 47 FET I - Mikrofon sa velikom dijafragmom
A LEGEND REBORN
Introduced in 1972 as a successor to the legendary U 47 tube microphone, the U 47 fet became a Neumann classic in its own right. Its smooth yet defined character shaped the sound of the 70s. After a long hiatus, the U 47 fet is finally available again, meticulously reproduced from the same components. A true classic, yet far from outdated.
Acoustical operating principle: Pressure gradient transducer
Directional Pattern: Cardioid
Frequency Range: 40 Hz ... 16 kHz
Sensitivity at 1 kHz into 1 kohm: 8 mV/Pa = –42 dBV ± 1 dB
Rated Impedance: 150 ohms
Rated load impedance: 1 kohms
Equivalent noise level, CCIR¹⁾: 25 dB
Equivalent noise level, A-weighted¹⁾: 18 dB-A
Maximum SPL for THD 0.5%²⁾: 137 dB
Maximum SPL for THD 0.5% with preattenuation²⁾: 147 dB
Signal-to-noise ratio, CCIR (re. 94 dB SPL)¹⁾: 69 dB
Signal-to-noise ratio, A-weighted (re. 94 dB SPL)¹⁾: 76 dB
Maximum output voltage: -3.3 dBu
Supply voltage (P48, IEC 61938): 48 V ± 4 V
Current consumption (P48, IEC 61938): 0.5 mA
Matching connector: XLR 3 F
Weight: 710 g
Diameter: 63 mm
Length: 160 mm
Opis nije dostupan
