Antelope Audio’s first ever studio monitor is designed to provide a cutting-edge modern solution for every studio. Atlas i8 delivers extended low-end frequencies and soaring sound pressure levels thanks to its secret weapon – two 8-inch woofers configured in an isobaric design. Atlas i8 brings sonic accuracy, pinpoint imaging and a fatigue-free listening experience as a result of meticulous acoustical engineering along with decades of research and development in the field of digital signal processing.

CLEAN AND ACCURATE LOW-END

• Isobaric bass configuration reduces cabinet size while maintaining optimal performance

• Two 8-inch woofers for precise low-end with minimum distortion even on high SPL

• Custom Class-D amplifier with low noise & harmonic distortion

• Thick 18mm cabinet with extra reinforcement, preventing any unwanted resonance frequencies

SIGNATURE SOUND QUALITY

• Digital calibration using FIR and IIR filters providing time-aligned neutral frequency response

• Coaxial driver for a single point axis response, also allows both horizontal and vertical positioning

• Proprietary 64-bit Acoustically Focused Clocking technology

• Ultra-accurate A/D and D/A conversion ensuring transparent and neutral signal

• 192kHz sample rate ensuring pristine conversion

WORKFLOW ENHANCING FEATURES

• Parametric EQ for frequency adjustments

• Software control panel for easy access to main features

• Color display with settings menu

• Delay offset to compensate for distance from the sweet spot

• AES digital I/O allowing daisy chain

• Optional mounting plate for wall/ceiling mount

TECHNICAL SPECIFICATIONS

• Frequency range: 35 – 20 000 Hz

• Max SPL: 117dB at 1 m with one speaker

• Amp wattage: 400W (200W low + 100W mid + 100W high)

• Input connectors: Analog XLR/TRS; Digital AES/EBU

• Output connectors: Digital AES/EBU

• Driver sizes: LF: 2×8″ isobaric, MF: 5,5″, HF: 1,5″ coaxial

• Speaker configuration: Three-way

• Active

• AD/DA converter: 24-bit/ 192 kHz

• Equalization: Digital parametric

• Enclosure Type: Front ported

• Dimensions: W 292 mm, D 387 mm, H 500 mm

• Weight: 24 kg
ADDITIONAL MEASUREMENTS

Coming soon

IN-THE-BOX CONTENT

• Atlas i8

• Power supply cable

• USB type A to B cable

• Getting Started leaflet
