System Specifications
Frequency Response: 38 Hz - 20 kHz (± 2 dB)
Low cutoff -6dB: 32 Hz
High cutoff -6dB: 25 kHz

SPL
Peak SPL: ≥120 dB
Maximum peak acoustic output per pair at 1 m distance with music material.
Short term max SPL: ≥110 dB
Maximum short term sine wave acoustic output on axis in half space, averaged from 100 Hz to 3 kHz at 1 m.
Long term max SPL: ≥101 dB
Maximum long term RMS acoustic output in same conditions with IEC weighted noise (limited by driver unit protection circuit) at 1 m.

Self-generated noise
Self-generated noise: ≤10 dB SPL
Self generated noise level in free field at 1m on axis (A-weighted).

Weight
Weight: 14.4 kg (31.7 lb)

Dimensions
Height: 433 mm (17 in)
Height with Iso-Pod: 452 mm (17 3/4 in)
Width: 286 mm (11 1/4 in)
Depth: 278 mm (11 in)

Enclosure material: Die cast aluminium
Enclosure type: Reflex port

Drivers
Bass
Driver type: Cone
Magnetically shielded.
Diameter: 205 mm (8 1/8 in)
Treble
Driver type: Metal dome
Magnetically shielded.
Diameter: 25 mm (1 in)

Harmonic distortion
50…100 Hz ≤2 %
> 100 Hz ≤0.5 %

Amplifier Section
Amplifiers
8050B bass amplifier: 150 W Class AB
8050B treble amplifier: 120 W Class AB

  100, 120, 220 or 230VAC 50/60Hz according to region

Power consumption
ISS Active: ≤0.5 W
Idle: ≤10 W
Full output: 170 W

Signal processing section

Input: Analog signal input connector XLR female, balanced 10 kOhm.

Crossover
Bass/Treble: 1800 Hz
