Genelec 8351B - Aktivni studijski monitor
A revolution in three-way monitor design, the 8351B boasts a unique look, compact size and a performance that has to be heard to be believed.
The upgraded 8351B now offers increased SPL, additional room compensation EQs, equalised delay and enhanced HF response. Offering the same extraordinary imaging and uncoloured precision of its smaller 8331A and 8341A siblings, the 8351B provides even greater LF extension, while its higher maximum SPL enables longer listening distances.
System Specifications
Frequency Response: 38 Hz - 20 kHz (± 1.5 dB)
Low cutoff -6dB: 32 Hz
High cutoff -6dB: 43 kHz
SPL
Peak SPL: ≥118 dB
Maximum peak SPL output per pair on top of console at 1 m with music material.
Short term max SPL: ≥113 dB
Maximum short term sine wave SPL output at 1 m on axis in half space, averaged as specified (from 100 Hz to 3 kHz).
Long term max SPL: ≥103 dB
Maximum long term RMS acoustic output in the same conditions with IEC weighted noise (limited by driver protection circuit) at 1 m.
Self-generated noise
Self-generated noise: ≤5 dB SPL
Self generated noise level in free field at 1 m on axis (A-weighted)
Weight
Weight: 14.3 kg (31.5 lb)
Dimensions
Height: 433 mm (17 in)
Height with Iso-Pod: 454 mm (17 7/8 in)
Width: 287 mm (11 1/4 in)
Depth: 278 mm (11 in)
Enclosure
Enclosure material: Die cast aluminium
Enclosure type: Reflex port
Drivers
Bass
Driver type: Racetrack
Dual 218 x 101 mm (85/8 x 4 in) obround cones
Count: 2
Width: 218 mm (8 5/8 in)
Height: 101 mm (4 in)
Midrange
Driver type: Coaxial
8351B midrange driver cone (coaxial)
Diameter: 130 mm (5 1/8 in)
Treble
Driver type: Coaxial
8351B treble driver metal dome (coaxial)
Diameter: 25 mm (1 in)
Harmonic distortion
50...100 Hz ≤2 %
> 100 Hz ≤0.5 %
Amplifier Section
Amplifiers
8351B bass amplifier: 250 W Class D
8351B midrange amplifier: 150 W Class D
8351B treble amplifier: 150 W Class D
Mains voltage: 100-240 VAC 50/60Hz
Power consumption
ISS Active: ≤1 W
Idle: ≤16 W
Full output: 200 W
Signal processing section
Connectors
Input: Analog signal input connector XLR female (10 kOhm input load impedance).
Input: XLR female (conforms to IEC 60958-4)
Output: XLR male (conforms to IEC 60958-4)
2 x Control: Two CAT5 (RJ45) GLM Network connectors for computer control using the Genelec Loudspeaker Manager (GLM) software.
Crossover
Bass/Mid: 320 Hz
Mid/Treble: 2800 Hz
