Key Specs
Channels of I/O: 26 Inputs / 38 Outputs
Maximum Sampling Rate: 192 kHz / 24-Bit
Number of Microphone Inputs: 8
Analog Audio I/O:
• 2x Combo XLR-1/4" TRS Mic/Line/Hi-Z Input
• 6x Combo XLR-1/4" TRS Mic/Line Input
• 74x 1/4" TRS Headphone Output
• 2x 1/4" TRS Monitor Output
• 2x 1/4" TRS Re-Amp Output
• 8x DB-25 Line/8-Channel Output
Digital Audio I/O:
• 2x ADAT Input
• 1x S/PDIF Input
• 2x ADAT Output
• 1x S/PDIF Output
Host Connection: 1x USB-C (on Interface)
Power Requirements: DC Input

General
Display: Color LCD
Channels of I/O: 26 Inputs / 38 Outputs
Built-In DSP: Yes
Maximum Sampling Rate: 192 kHz / 24-Bit
Number of Microphone Inputs: 8
Built-In Microphone: (Talkback)
Input Level Adjustment: 8x Knob

Connectivity
Analog Audio I/O:
• 2x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line/Hi-Z Input (Front Panel)
• 6x Combo XLR-1/4" TRS Balanced/Unbalanced Mic/Line Input
• 4x 1/4" TRS Headphone Output (Front Panel)
• 2x 1/4" TRS Monitor Output
• 2x 1/4" TRS Re-Amp Output
• 8x DB-25 Line/8-Channel Output
Phantom Power: 48 V
Digital Audio I/O:
• 2x TOSLINK Optical ADAT Input
• 1x RCA Coaxial S/PDIF Input
• 2x TOSLINK Optical ADAT Output
• 1x RCA Coaxial S/PDIF Output
Host Connection / USB: 1x USB-C (on Interface)
Host Connection Protocol: USB 2.0
USB (Non-Host): No
Sync I/O:
• 1x BNC Word Clock Input
• 3x BNC Word Clock Output
Network I/O: No
MIDI I/O: No
Expansion Slots: No
Other I/O: 1x 1/4" Footswitch Input
Wireless: No

Digital Audio
Sample Rates: Up to 192 kHz
Bit Depths: 24-Bit
Sync Sources: ADAT, S/PDIF, Word Clock

Audio Storage & Playback
Media/Memory Card Slot: No

Compatibility
OS Compatibility: macOS / Windows
Required Hardware: USB Cable

Power
Power Requirements: DC Input
AC/DC Power Adapter: 18 VDC
Power Consumption: 20 W (Maximum)

Physical
Rackmount Size: 1 U
Dimensions: 19" / 48.3 cm

Packaging Info
Package Weight: 8.51 lb
Box Dimensions (LxWxH): 25.6 x 14.4 x 3.8"
