MOTU 8pre USB - zvučna kartica
16 x 12 USB audio interface with 8 mic inputs
Turn your computer into a powerful digital audio workstation with eight mic inputs. Or add eight high-quality mic/instrument inputs to your current system.
The 8pre audio interface delivers everything you need to turn your computer into a powerful 24-bit, 96kHz digital audio workstation. The 8pre provides eight microphone/instrument preamps with pristine 96kHz analog recording and playback, combined with 8 channels of ADAT optical digital I/O. Expand your system by connecting additional 8pres or other MOTU audio interfaces.
General
Channels of I/O: 16 Input / 12 Output
Built-In DSP: No
Maximum Sampling Rate: 96 kHz / 24-Bit
Number of Microphone Inputs: 8 Preamps
Built-In Microphone: No
Expansion Slots: No
Signal Processing
Pad: No
High-Pass Filter: No
Solo/Mute: No
Connectivity
Analog Audio I/O:
• 8x Combo XLR-1/4" TRS Input
• 1x 1/4" TRS Headphone Output
• 2x 1/4" TRS Monitor Output
Digital Audio I/O:
• 2x TOSLINK Optical ADAT Input
• 2x TOSLINK Optical ADAT Output
Host Connection: USB-B
Host Connection Protocol: USB 2.0
USB (Non-Host): No
Sync I/O: No
Network I/O: No
MIDI I/O: No
Digital Audio
Sample Rates: Up to 96 kHz
Sample Rate Conversion: No
Bit Depths: Up to 24-Bit
Compatibility
OS Compatibility:
• macOS 10.6
• Windows 7 or Later
Included Software: No
Included Plug-Ins: No
Power
Power Requirements: AC/DC Power Adapter (Included)
Physical
Rackmount Size: 1 U
Dimensions: 19 x 7 x 1.75" / 48.26 x 17.78 x 4.45 cm (without Rack Ears)
Packaging Info
Package Weight: 6 lb
Box Dimensions (LxWxH): 23.5 x 11.4 x 5.5"
