General
Display: No
Channels of I/O: 10 Input / 14 Output
Built-In DSP: Floating-Point
Maximum Sampling Rate: 192 kHz / 24-Bit
Number of Microphone Inputs: 1
Built-In Microphone: No

Signal Processing
Pad: No
High-Pass Filter: No
Solo/Mute: No

Connectivity
Analog Audio I/O:
• 2x Combo XLR-1/4" TRS Mic/Line Input
• 6x 1/4" TRS Balanced/Unbalanced Line Input
• 10x 1/4" TRS Line Output
• 1x 1/4" TRS Headphone Output
Phantom Power: 48 V
Digital Audio I/O:
• 1x RCA Coaxial S/PDIF Input
• 1x RCA Coaxial S/PDIF Output
Host Connection:
• 1x FireWire 6-Pin (Class-Compliant, on Interface)
• 1x USB-B (Class-Compliant)
Host Connection Protocol:
• FireWire 400
• USB 2.0
USB (Non-Host): No
Sync I/O: No
Network I/O: No
MIDI I/O:
• 1x DIN 5-Pin Input
• 1x DIN 5-Pin Output
Expansion Slots: No
Wireless: No

Digital Audio
Sample Rates: 44.1 / 48 / 88.2 / 96 / 176.4 / 192 kHz
Bit Depths: 24-Bit
Sync Sources: Internal, S/PDIF

Audio Storage & Playback
Media/Memory Card Slot: No

Compatibility
OS Compatibility: Windows / macOS 10.4 Only
OS Compatibility:
• Windows
• macOS 10.4
Mobile App Compatible: No
Required Hardware: FireWire 400 Port, FireWire 800 Port, USB 2.0 Port

Power
Power Requirements: AC/DC Power Adapter (Included)
AC/DC Power Adapter: 10 to 24 VDC

Packaging Info
Package Weight: 5.6 lb
Box Dimensions (LxWxH): 15 x 11.4 x 5.5"
