Mic Inputs 1-2
Dynamic Range: 136 dB-A
Equivalent Input Noise (150 Ohm): -128 dBu-A
Input Impedance: 10 kΩ
Gain Range: 12…+78 dB in 0.5 dB steps or 0.1 dB (fine)
Pad: 12 dB/24 dB
Max. Input Level: 0 /+12/+24 dBu (without Pad/with Pad)
THD + N Preamp + ADC @ 1 kHz, 0 dBFS: < -110 dB (0.0003%)

Line Inputs 1-2
Dynamic Range: 138.5 dB-A
Input Impedance: 10 kΩ
Gain Range: 0…+66 dB
Sensitivity: +24 dBu…-42 dBu
Max. Input Level: +24 dBu
THD + N Preamp + ADC @ 1 kHz, 0 dBFS: < -105 dB (0.0006%)
Instrument/Line Inputs 3 - 4
Dynamic Range: 135 dB-A
Input Impedance: 2 MΩ (balanced) / 1 MΩ (unbalanced)
Gain Range: 0…+66 dB
Sensitivity: +18 dBu … -48 dBu
Max. Input Level: +18 dBu
THD + N Preamp + ADC @ 1 kHz, 0 dBFS: < -112 dB (0.0003%)

Line/Monitor Outputs
Output Impedance: < 70 Ω
THD+N@ 1 kHz, 0 dBFS: < -110 dB (0.0003%)
Dynamic Range: 123 dB-A
Max. Output Level: +24 dBu

Headphone Outputs
Output Impedance: 0.035 Ω
Dynamic Range: 122 dB-A (high) / 117 dB (low)
Max. Output Level: +16 dBu (high) /+8 dBu (low)
AES67/Ravenna: Standard RJ-45 Gigabit-Ethernet-Anschluss
Expansion Connectivity: "ADAT/S/PDIF optical I/O, MIDI I/O via 1/4” jack, (DIN5 adapter set available from Neumann: Cat. No.700261)"
Computer Interface: USB-C, 2.0 High Speed (480 MB/s) or higher
Power Consumption: <25 W
Product Dimensions: 200 x 128 x 40mm
