Power Amplifier
Number of Powered Channels: 11
Power Output (8 ohm, 20 Hz - 20 kHz, 0.08% 2ch Drive): -
Power Output (8 ohm, 20 Hz - 20 kHz, 0.05% 2ch Drive): 140 W
Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive): 175 W
Power Output (6 ohm, 1 kHz, 10% 1ch Drive): 250 W
70% Guarantee: Yes
Discrete Power Amplifier: Yes
Amplifier Topology: Class A/B
Current Feedback Topology: yes
Bi-Amp Drive: assignable

Multichannel Surround Technologies
DTS: DTS HD Master, DTS:X, DTS:X Pro, DTS Neural:X, DTS Virtual:X
Dolby: Dolby TrueHD, Dolby Atmos, Dolby Atmos Height Virtualization, Dolby Atmos Music, Dolby Surround
Other
Max Number of Processing (Preamp) Channels: 13.4
IMAX Enhanced: Yes
Auro 3D: Yes
Audyssey DSX: Yes
Multichannel Stereo: Yes

Inputs Outputs
Composite In / Out: 2 / 0
Component In / Out: 1 / 0
HDMI In / Out: 7 / 3
Multi-Room Video Out via HDMI: 0 / 0
Analog In / Fixed Level Out: 3 in / 0 out
Phono (MM) In: Yes
Digital In: Optical / Coaxial: 2 / 2
Multi-Room Out: analog / digital: 2 / 0
Multichannel Preamp Out: 7.2
Subwoofer Out: 4 (independent)
7.1 multichannel input: No
Number of Speaker Terminals: 13
Speaker A / B: assignable
Multi-Room Speaker Terminal: assignable
Front Inputs: USB-A
USB Audio: Yes / No / No
FM Tuner with RDS: Yes
DAB+ Tuner: No
Multi-Room Video Out: Video / HDMI: 7/3
analog In/out: 6 / 0
Multichannel Pre Out: Yes (13.4)
Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB: No / No / No / No / Yes

HDMI
Total HDMI Inputs / No. Support 8K: 6 / 3
HDCP2.3 support: Yes
HDMI Outputs: Main / Zone: 2 / 1
Analog to HDMI Video Conversion: No
HDMI Upscaling: 1080P/4K to 8K
Max resolution @ framerate
Audio Return Channel: ARC, eARC
Video Dynamic Range: HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR
ALLM (Auto Low Latency Mode) Pass-through for gaming: Yes
Variable Refresh Rate / Quick Frame Transport: Yes / Yes / No
HDMI Pass-Through in Standby Mode: Yes
CEC: Yes
DSD Audio over HDMI: No
Auto LipSync: Yes
HDMI Inputs: Back / Front: 7 / -
Video Conversion Analog -> HDMI: Yes
HDMI to HDMI Scaling: 1080P/4K to 8K
HDMI 2.1: 8K/60Hz AB / 4K/120Hz AB: Yes / Yes
8K/60Hz AB / 4K/120Hz AB Pass-through In/Out: 7 / 2 (up to 40Gbps)
HDMI 2.0: 3D / 4K / CEC / ARC: Yes / Yes / Yes / Yes
HDR / HLG / Dolby Vision / HDR10+ / Dynamic HDR: Yes / Yes / Yes / Yes / Yes
Variable Refresh Rate / Quick Flame Transport / Quick Media Switching: Yes / Yes / No
8K signal pass-through / scaling / GUI overlay: o / o / o
4K Signal Pass-Through / Scaling / GUI Overlay: o / o / o
DSD Audio Capability: Yes

Performance Technologies
Copper Plated Chassis: Yes
Toroidal Power Supply Transformer: Yes
Hyper Dynamic Amplifier Modules (HDAM) (List version): Yes
Pure Direct Mode: Yes
Gold Plated RCA Terminals: Yes
Clock Jitter Reducer: Yes

Acoustic Room Correction
Audyssey: MultEQ XT32
Audyssey Dynamic EQ / Dynamic Volume: Yes / Yes
bYes
Dirac Live Support: Yes
Variable Cross Over: Yes
Optimized Bass Redirection: Yes
Bass Sync: Yes
Dirac Live Upgradability: Yes

Music File Support
Lossy Formats: MP3 / WMA / AAC
Lossless formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/31
DSD Audio: 2.8 MHz / 5.6 MHz
Gapless Playback: FLAC, WAV ,ALAC ,DSD
Compressed Audio Enhancer: MDAX2: Yes
Network Audio Sharing: Yes

Streaming Services
HEOS Multi-room and Streaming: Yes
AirPlay Audio Streaming: AirPlay2
Internet Radio: TuneIn
Spotify*: Spotify Connect
Pandora: No
SiriusXM: Yes
Other Streaming Services *: Amazon Music HD/Amazon Music / TIDAL / Deezer / Napster / Soundcloud / Mood Mix
Roon tested: Yes

Network Connectivity
Ethernet Ports: Yes
Wi-Fi (include version / band): Yes
Bluetooth (Include version): Yes
Bluetooth Re-transmit for Bluetooth headphones: Yes

Smart Home Integration and Control
Voice Assistant Compatibility: Alexa / Google Voice Assistant / Apple HomePod
App for Smart Phones & Tablets (iOS & Android): Marantz AVR App
HEOS Multi-Room Integrated: Yes
HEOS Link Compatibility: IR/ IP: Yes /Yes
Multi-Room zones: 2
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog: 2 Ch / 2 Ch / Yes / Yes
Zone Audio Output: Speaker / Preout: Yes / Yes
Zone HDMI Output from HDMI Source: Yes
Control Connectivity: IP Control / RS232 Control / Web Control / App Control
IR Flasher In: Yes
Marantz Remote Bus: Yes
DC Trigger Output: 3
HDMI Diagnostics: Yes

Others
Front Display: 2 line FLD + port hole OLED
Primary Display Size (diagonal in/mm)
Secondary Display Size (diagonal in/mm)
GUI Languages: 3
Setup Assistant: Yes
Smart Select on Remote: Yes
Firmware Update by Network / USB: Yes / Yes
ECO Mode: Yes
Auto Power off: Yes
Sleep Timer: Yes
GUI Overlay on HDMI
CEC: Yes
Auto Speaker Setup by Microphone: Audyssey MultEQ XT32Dirac Live (upgrade)
Graphic User Interface - GUI: Modern HD GUIModern HD GUI
Smart Select: Yes

General
Available Colors: Black/Silver-Gold
Metal Front Panel: Yes
System Remote Control: RC-051SR
Power Consumption in W: 780
Power Consumption No-Sound (ECO on/off) in W: 65 W / 110 W
Standby Consumption in W: 0.2
CEC Standby Consumption in W: 0.5
Network Standby Consumption in W: Less than 2.0
Maximum Dimensions
Antenna:Horizontal:(W x D x H) in mm: 442 x 457 x 189
Antenna:Vertical :(W x D x H) in mm: 442 x 457 x 257
W/o Antenna:(W x D x H) in mm: 442 x 447 x 189
Weight in kg: 19.4
What's in the box: Main unit, remote control, batteries, AM/FM antennas, wire labels, quick start guide, Audyssey microphone, cardboard microphone stand, 2 External Detachable Antennas, AC cord
Pre-Programmed / Learnable / LCD Display: Yes / Yes / Yes
