Q Acoustics SUB80 Subwoofer Satin Black - Aktivni vufer
Smaller rooms with smaller speakers still deserve big, well-controlled bass for listening to music or watching movies. The Q SUB80 with its 8in driver is the ideal partner for M20 or M40 active speakers or 3000c and 5000 Cinema Packs in ones or twos.
KEY FEATURES
• Q SUB80 has exceptional bass power to cabinet size ratio.
• This subwoofer is more powerful than the previous QB 12 model.
• Digital Signal Processing (DSP) allows easy system and room integration with optimise settings for class-leading, distortion-free performance.
• Clever, dual phase and delay controls allow the fine-tuning of the signal alignments for flexible room placement.
• DSP identifies the input signal and automatically adjusts system gain, enhancing performance regardless of the connected source.
• A low pass filter with frequency adjustment ensures seamlessly integration with any partnering speaker system.
• A custom-designed amplifier module features four digital power amplifier stages that improves efficiency by dissipating less heat, enhances speaker control, and reduces output impedance.
SPECIFICATIONS
• Enclosure type: Infinite baffle
• Bass unit diameter: 203 mm (8 in)
• Effective volume: 13.9 litres
• Max SPL @ 1 m: 107 dB
• Frequency response (-6dB): 36 Hz – 250 Hz
• Low pass crossover range: 50 Hz – 250 Hz
• Peak amplifier power: 400 W
• Continuous amplifier power: 200 W
• THD @ rated power: 0.09%
• Input sensitivity (max gain): 300 mv rms
• Maximum input level: 2.1 V rms
• Input impedance: 20 kΩ
• Noise floor (A wtd): 50 μV
• Dimensions (HxWxD): 315 x 315 x 347 mm (12.4 x 12.4 x 13.6 in)
• Weight (per loudspeaker): 15 kg (33 lbs)
