JBL Synthesis SCL2XL
2.5-way Quadruple 8-inch (200mm) In-Wall Loudspeaker
Designed to deliver high output, the SCL-2XL is a custom in-wall loudspeaker perfectly suited for use as an LCR behind an acoustically transparent projection screen or as surrounds in larger systems. It features JBL’s patented D2815 dual 1.5-inch (38mm) compression driver mated to a large format High-Definition Imaging (HDI™) horn. Quadruple 8-inch (200mm) Advanced Aluminum Matrix cone cast-frame woofers operate in a 2.5-way network configuration allowing for installation vertically or horizontally without lobing or other acoustic issues found in traditional designs. The integrated MDF enclosure is designed for installation in standard 2x6 wood frame construction, and internal connections allow for bi-wiring or bi-amplification in advanced installations. The SCL-2XL delivers unparalleled performance in a wide variety of applications and is ideal for use in medium, large, and extra-large rooms.
Type: 2½‑way in‑wall loudspeaker
Low Frequency Driver: Quad 8-inch (200mm) cast-frame, Advanced Aluminum Matrix cone woofers
High Frequency Driver: D2815, 1.5" (38mm), dual annular ring Teonex® diaphragm compression driver mounted to Sonoglass® horn/baffle
Inputs: Dual set of spring-loaded gold-plated binding posts for bi-amp/bi-wire capability (crossover not defeated)
Power Handling: 500 Watts RMS (CEA-426B specification, at rated load impedance)
Frequency Response: 53Hz – 25kHz (-6dB)
Coverage Angle (-6dB): 110° Horizontal, 90° Vertical, averaged over 2kHz-10kHz
Sensitivity (2.83V@1m): 92dB
Impedance: 4Ω nominal, 3.2Ω minimum @ 800Hz
Crossover Frequencies: 450 Hz, 1.1 kHz
Finished Dimensions with Grille (H x W x D): 45.7” x 14.2” x 6.2” (1161mm x 361mm x 156.8mm)
Mounting Depth with Backbox: 5.4” (136mm)
Product Weight: 77lbs (35kg)
Shipping Weight: 103lbs (47kg)
Enclosure type: Sealed in-wall mount with included backbox
Finish: Matte Black with white paintable grille
