Product


Connector Type
Speakon®


Gender
female


Electrical


Contact resistance
< 2 mΩ (after lifetime)


Dielectric strength
4 kVdc (peak)


Insulation resistance
> 1 GΩ (after dampheat)


Rated current per contact
40 A rms continuous


Rated current per contact
50 A audiosignal, duty cycle 50 %


Rated voltage
250 V (Insulation)


Mechanical


Cable O.D.
7 - 14.5 mm


Cable retention force
≥ 220 N (subject to cable O.D. and material)


Lifetime
> 5000 mating cycles


Wire size
4 mm² / 6 mm² (screw type terminals/soldering)


Wire size
12 AWG / 10 AWG


Wiring
screw type terminals or soldering


Locking device
Quick Lock (latch)


Material


Bushing
Polyamide (PA 6 15 % GR) black


Contact plating
4 µm Ag


Contacts
Brass (CuZn39Pb3)


Insert
PBTP 20 % GR


Locking element
Zinc diecast (ZnAl4Cu1)


Shell
PBTP 20 % GR


Strain relief
Polyacetal (POM)


Environmental


Approvals
UL,CSA


Flammability
UL 94 HB


Solderability
Complies with IEC 68-2-20


Temperature range
-30 °C to +80 °C
