Features
• Compact passive two-way system
• Lightweight, portable with a discreet design
• Peak SPL of 125dB (131dB with crest factor 4)
• Differential Dispersion horn
• Dispersion: 100°–120° horizontal × 40° vertical
• Screw-tight, cloth-backed perforated steel grille
• Pole-mount cover maintains clean lines
• 8Ω nominal impedance
• One NL4 connector
• Flexible mounting options via M8 inserts

Applications
• Portable sound reinforcement
• Bars and restaurants
• Corporate AV events and conferences
• Weddings and parties
• Houses of worship

Type: Passive two-way compact column loudspeaker
Frequency response: 69 Hz – 17 kHz ± 3 dB, -10 db @ 53 Hz
Driver (LF): Dual 6” (150 mm) with 1.5” (38 mm) voice coil, ferrite motor system
Driver (HF): 1" (25 mm) exit compression driver with 1" (25 mm) voice coil, PETP dome
Rated power: 300 W AES, 1200 W peak
Required electronics: Processor and amplifier, or a combined amplifier-processor unit
Recommended electronics: DX0.4, DX0.6 or DX4.0 system processor and VIA amplifier, or iKON amplifier-processor
Sensitivity: 94 dB
MAXIMUM SPL: 119 dB continuous, 125 dB peak, 131 dB peak with crest factor 4
Nominal impedance: 8 ohm
Dispersion: 100°–120° (horizontal) × 40° (vertical)
Crossover: 2.4 kHz passive
Enclosure: Durable plywood
Finish: Black or white textured paint
Protective grille: Black or white perforated steel grille with scrim cloth backing
Connectors: 1 x NL4 connector
Pin connections (input): 1+/1–
Pin connections (link): NA
Fittings:
• 3 x M8 inserts, 1 x M6 insert, 4 x M6 inserts for wall bracket
• 1 x pocket handle made from recycled ABS
• Pole-mount socket with removable cover
Dimensions:
• (W) 193 mm x (H) 670 mm x (D) 218 mm
• (W) 7.6 in x (H) 26.4 in x (D) 8.6 in
Weight: 9.5 kg (20.9 lbs)
