AES/EBU, AES/EBUid and S/P-DIF optical/coaxial interfaces in one box
Uni- and bi-directional format conversions up to 192.0 kHz between AES3/AES3id and S/P-DIF
Signal improvement and stabilization by low-jitter PLLs
Converts to all output formats simultaneously while allowing the original signal to pass through
Works as active signal splitter for AES3/AES3id and S/P-DIF
Every interface standard offers two separately buffered outputs
Detects NONE-PCM and DTS bitstreams
SCMS processing and status analysing
User‘s settings will be stored after switching-off
New-designed, simple user interface
Rack-space-saving 9.5“ housing
Built-in, internationally useable power supply

High-Performance Audio Conversions in all Respects
Due to the increasing number of devices with AES/EBU or AES/EBUid and S/P-DIF interfaces found in every studio environment, often a problem of different transmission formats and interface standards occurs mostly when those devices should exchange their digital audio data. At this point the MC1.1+ comes in and helps you to convert problem-free between the most popular digital audio formats and interface standards: AES3 and S/P-DIF. Using latest low-jitter audio PLLs and a low-noise PCB circuit design, the MC1.1+ not only converts, but also regenerates and improves your digital audio signal with clock rates up to 192.0 kHz. Thereby, the format conversion process does not only the necessary electrical conversion but also a real format conversion of the reference signals in compliance with the specifications standardized by the Audio Engineering Society (AES) and the International Electrotechnical Commission (IEC). This feature truly helps you to avoid incompatibility problems of the used signal formats between the connected devices during conversion. Thus, you can rely on professional conversions with help of the MC1.1+ in all respects!

Outstanding Flexibility
Various operation modes enable the use of the MC1.1+ in many applications. Nearly every imaginable conversion between the involved formats is possible! Incoming digital audio signals are uni-directionally converted to four output formats at once, whereas every format offers two outputs for additional signal splittings. As for bidirectional format conversions, the MC1.1+ provides real double circuitries which allow for the first time converting the formats of two signals even with different sampling rates at the same time. A special splitting mode offers to actively split four individual input signals to their respective double outputs simultaneously. The SCMS status of S/P-DIF signals can be monitored and adapted in every operations mode. Thus, the MC1.1+ offers highest flexibility to solve interconnections problems in your studio very easy and reliable!
