ChamSys GeNetix GN5 5Port Node
GeNetix Node 5 is a multipurpose node that provides a solution for remote data distribution in a wide variety of applications, notably offering support for Timecode, MIDI and 10Scene.
This universal interface supports Art-Net, sACN, RDM and like all GeNetix nodes is fully configurable from ChamSys consoles, via its in-built web server or via the display on the unit. Its DMX ports are fully configurable, allowing for use as DMX Input or Output and has configurable DMX timings. With two network ports, GeNetix Node 5 can be either PoE or Mains powered via its powerCON TRUE1 line input. This versatile device is at home in many different environments as a standalone interface, truss-mounted in the rig via its M12 receiver, installed via its DIN rail mount or rack mounted via its optional rack ears.
Hardware Specifications:
RDM Direct DMX Ports: 5
Network Ports: 2
MIDI Ports: 2 (1 in, 1 out)
LTC Timecode Ports: 2 (1 in, 1 out)
10Scene Ports: 1
PoE Input: Yes (Port 1)
USB Ports: 1 USB-C
Kensington Security Lock Fixing: Yes
Power Input, Neutrik powerCON TRUE1 110 to 240 VAC
Max Power Consumption (mains): 60w
Included Accessories:
DIN Rail Mount Clip: 1
Neutrik powerCON TRUE1 Power Cable: 1
Countersunk Screws: 3
Quick Start Guide: 1
Screws: 8
Rack Mounts: 2
USB A-C Cable: 1
Phoenix Connectors: 2
Software Specifications:
Art-Net/sACN: Yes
ChamNet Support: Yes
LTC & MIDI Timecode over ChamNet: Yes
MIDI Notes over ChamNet: Yes
10Scene Gateway Functionality: Yes
Configurable DMX Timings: Yes
Web Server: Yes
DMX Redundancy Support: Yes
User Scene Store: Yes
Recall Scenes Via UDP: Yes
Node Weights and Dimensions:
Width: 250mm (9.84 inches)
Depth: 172mm (6.77 inches)
Height:44.4mm (1.75 inches)
Weight: 1.4 KG (3.08 lb)
