JBL Control 50 PACK White
Packaged Surface-Mount Subwoofer-Satellite Loudspeaker System
The Control 50 Series subwoofer-satellite loudspeaker system provides high fidelity sound in restaurants, retail stores, music cafes, health clubs, theme bars, leisure venues, or any location where full-range high fidelity foreground/background music is required from surfacemount system.
Features
• Versatile four satellite speaker system
• Stylish, unobtrusive design fits into a wide variety of decor
• High fidelity sound
• Selectable 70V/100V for distributed lines, or low impedance
• Wall-mount brackets include
• Available in black or white
Frequency Range (-10dB): 32 Hz – 20 kHz
Frequency Response (±3 dB): 50 Hz – 17 kHz
Power Rating:
• 200 Watts Continuous Program Power (100 hrs)
• 100 Watts Continuous Pink Noise (100 hrs)
Sensitivity:
• System: 87 dB with 4 satellites
• 85 dB with 2 satellites
(depends on subwoofer boundary loading, see application note)
Impedance: 4 ohms with 4 satellites, 8 ohms with 2 satellites
Transformer Taps: 80W, 40W, 20W, (& 10W @ 70V), plus bypass/thru (listed as 8 ohms on switch to indicate subwoofer impedance
Maximum SPL (1m):
• System: 107 dB with 4 satellites, continuous (113 dB peak)
• 105 dB with 2 satellites, continuous (111 dB peak)
(depends on subwoofer boundary loading, see application note)
Input Connectors: Removable locking 2-pin connectors with screw-down terminals.
Grille: Zinc-plated steel
Mounting Hardware:
• C50S/T: 2-part flush wall-mount bracket included.
• C52: Wall swivel ball bracket included
Included Accessories: See Control 50S/T & Control 52
Coverage Angle: Omnidirectional
