OPTICS
2-element 10:1 zoom high-resolution optic system
Beam aperture: 3° to 30°
5 x Fast motorised linear zoom
Tempered anti-reflective coated lenses
5  x 100 mm front lens
LIGHT SOURCE
5 x 5,000 lm RGB-L led sources
Total luminaire output: up to 15,000 lumens (integrating sphere measurement, Fan mode STAGE)
Illuminance at 5m: 16,000 lux (one head)
CRI: up to 86
Rated life (L70): up to 40,000 hours
Flicker-free source management suitable for TV applications and all video-recorded events
MOVEMENT
Highly accurate positioning
Moving-head operated via 16-bit resolution
High-resolution stepper motors operated via microprocessors to ensure extreme accuracy and smooth movement
Pan and tilt automatic repositioning
Moving-head range: 5 x infinite pan and tilt rotation
COLOURS
Sophisticated 4 colours RGB-L mixed, reaching high Colour Rendering Index
Uniform light beam with no colour shadows, and rich saturated and pastel colour-hues
4.29 billion colours (8-bit resolution)
Virtual CTC channel, from 2500 to 8000K
Virtual Tint channel
EFFECTS
Individual control of each head
Liquid Effect with 60 individual pixels
Built-in pattern effects for main leds and Liquid Effect, with speed and fade controls
DIMMER / STROBE
Electronic dimmer from 0 to 100%
Strobe effect: 1 to 25 flashes per second
HARDWARE FEATURES
Graphic LCD display with flip function
4 menu buttons to set functions
Integrated wireless CRMX TiMo RDM receiver from LumenRadio
IP65 XLR 5 pin male and female connectors for DMX connection
IP65 RJ45 IN / OUT connectors for ethernet connection
IP65 Power male and female connectors for power connection
Maximum current available at the output socket : 12 A
CONTROL
DMX 512 protocol, through DMX cable or a wireless system
DMX-RDM compatible
Stand-alone mode and Main/Follow modes
ArtNet & sACN protocol through Ethernet cable
Local control panel, with IP65 LCD display
Footprint of 175 or 184 DMX channels
PWOER SUPPLY

Electronic power supply with active PFC
100 to 240 Volts – 50/60Hz
Power: 800 W maximum
COOLING SYSTEM
Advanced liquid cooling system
IP68 Self-adjusting variable speed fans
Selectable ventilation user modes
Excess temperature protection
HOUSING
Moving-head skeleton made in die-cast aluminium
Base in die-cast aluminium
Heatsinks in aluminium and copper
Moulded covers in ABS PC (V0 class)
Tow-side handles for transportation
Four heavy-duty feet
IP65 protection rating
Exterior finish: black (Carbon)
INSTALLATION
Fastening bracket system: two Omega ¼ turn brackets designed for use with standard clamps
Mounting points: eight ¼ turn locking fittings allowing installation of two Omega brackets on luminaire
Safety cable attachment point
OPERATING PARAMETERS
Operating positions: all (device on floor or fixed to a support)
Maximum permitted ambient temperature (Ta max): 45° C (113° F)
Minimum permitted ambient temperature (Ta min): -20° C (-4° F)
Minimum usage distance: 0.5 m (1.64 ft.)
COMPLIANCE
EU (EMC & LVD):
EMC Directive 2014/30/EU
LVD Directive 2014/35/EU
US (Safety & EMC)
CFR 47, FCC Part 15, Subpart B:2023
Substance regulations
RoHS
REACH
CP65
SIZE
Product: 1008 x 200 x 352.5 mm (l x h x d)
Flight-case foam: 1080 x 270 x 380 mm (l x h x d)
WEIGHT
Product: 32.4 kg
