GENERAL
Height: 1.75 inches (44 mm)
Width: 8.5 inches (216 mm)
Depth: 10.4 inches (264 mm)
Weight: 4 lbs (1.8 kg)

ENVIRONMENTAL
Ambient Operating Temperature Range: 32 - 104° F (0 - 40° C)
Humidity: 0-95% relative humidity (non-condensing)
Altitude: 0-6,600 ft (0-2000m) MSL

POWER
Power: Current Draw (100-240VAC 50/60Hz): 0.5-0.21A
Phantom Power: +48 VDC (7mA/input)
Current Draw: (100-240VAC 50/60Hz) = 0.5-0.21A

CONTROLS & INDICATORS
Control: RJ-45 with Ethernet cable (Cat 5e and above)
Logic I/O:
• Logic Input Trigger: Contact Closure or 5V TTL
• LED Driver: 5V/10mA per output
• Logic Output Type:
• Open Collector; Sink 40V/300mA per output
RS-232: 115200/8-N-1

MEDIA
1 Gb: RJ-45 with Ethernet cable (Cat 5e and above)
10 Gb: 10G fiber SFP+

VIDEO
Supported Resolution: Up to 4K60
Physical Interfaces: HDMI, DisplayPort
Colorspace: Up to Rec. 2020
Color Formats: YUV, RGB
Chroma Sampling: 4:4:4, 4:2:2, 4:2:0
Color Bit Depth: 8-bit, 10-bit, 12-bit, 16-bit
Network Transit Latency: 1.5 frames (25ms @ 60fps)
HDMI Audio Formats: 8ch PCM

AUDIO
Crosstalk:
• Channel to channel 1kHz = 0dB gain
• +4dBu input: < -85dB
• 54dB gain
• -50dBu input: < -75dB

CERTIFIED SOLUTIONS
TAA Compliant: TAA Compliant

COMPLIANCE
Certifications:
• FCC Part 15B (USA)
• UL and C-UL (USA and Canada)
• CE Marked (Europe)
• RoHS Directive (Europe)
